Altronix ReServ2 Quick Start Manual

ReServ2 Video Surveillance UPS is designed to provide power for 24VAC cameras during normal or power outage
conditions. True sine wave regulated AC outputs.
Input:
• 115VAC 60 Hz, 1.9 amps.
Output:
• 24VAC outputs.
• Sixteen (16) PTC protected outputs.
• 4 amp (100VA) total supply current.
Output Ratings:
• PTC protected outputs are rated @ 1 amp.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switchover to stand-by battery
when AC fails.
Visual Indicators:
• Individual power LED indicator.
• AC input power output LED indicators.
This installation should be made by qualified service personnel and should conform to all local codes and in accordance
with the National Electrical Code. Product is intended for indoor use only. This product contains no serviceable parts.
1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure's
upper keyholes over the two upper screws, level and secure.
Mark the position of the lower two holes. Remove the enclosure. Drill the lower holes and install the two fasteners.
Place the enclosure's upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten
all screws (Enclosure Dimensions, pg. 4). Secure enclosure to earth ground.
2. Connect AC power mains to terminals marked [L & N], connect ground to terminal marked [G] (Fig. 1f, pg. 2).
Use 18 AWG or larger for all power connections (Battery, output) (Figs. 1b & 1d, pg. 2).
Use 18 AWG to 22 AWG for power limited circuits (AC Fail/Low Battery reporting) (Fig. 1c, pg. 2).
3. LED on the ReServ2B board will illuminate when AC power is present.
4. Measure output voltage before connecting cameras/devices to outputs. This helps avoid potential damage.
5. Connect 24VAC cameras/devices to terminals marked [1-16] (Fig. 1d, pg. 2).
6. Unit provides an audible alarm when the following conditions occur; AC fail, Low Battery, Output power shutdown.
To disable the audible alarm remove jumper (Fig. 1a, pg. 2).
7. The power LEDs on the unit for Outputs 1-16 will illuminate when AC power is present (Fig. 1d, pg. 2).
Note: If any of the power LEDs are not illuminated the cause may be due to the following:
a. AC mains and battery fail.
b. One (1) or more power output PTCs are tripped due to a short circuit or overload condition.
c. Unit damaged/defective.
To reset the PTC:
1. Disconnect corresponding camera/device connected to terminals marked [1-16] (Fig. 1d, pg. 2).
2. Eliminate the trouble condition (short circuit or overload).
3. Allow 1 minute for PTC to cool off (reset).
4. Connect corresponding cameras/devices to terminals marked [1-16] (Fig. 1d, pg. 2).
5. Power LEDs will illuminate indicating power has been restored to outputs (Fig. 1d, pg. 2).
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes and in
accordance with the National Electrical Code.
ReServ2
ReServ2
®
Video Surveillance UPS
Overview:
®
Specifications:
Visual Indicators (cont'd):
• Low battery and output power shutdown LED indicators.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).
Special Features:
• True sine wave regulated AC output.
• Audible alarm provides notification of
UPS trouble conditions.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates costly labor.
Enclosure:
• Enclosure accommodates up to two (2)
12VDC/7AH batteries.
• Dimensions: 13.5"H x 13"W x 3.25"D
Installation Instructions:
Rev. 100609
- 1 -
