- Page 1 ReServ5WP Outdoor Video Surveillance UPS Installation Guide More than just power. Rev. 092816...
- Page 2 Overview: ReServ5WP Video Surveillance UPS unit is designed to provide power for 24VAC and 12VDC cameras during normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs. Specifications: Agency Listings: Battery Backup (cont’d): UL 60950-1 UL/CUL Listed for Information •...
- Page 3 To reset the PTC: 1. Temporarily remove wiring from output with tripped PTC (Fig. 1, pg. 4). 2. Eliminate the trouble condition (short circuit or overload). 3. Allow 1 minute for PTC to cool off (reset). 4. Re-attach wiring to the output (Fig. 1, pg. 4). 5.
- Page 4 Fig. 1 - ReServ5WP Ground Lug Non power-limited Input --- 24VDC + Unswitched 115VAC 60Hz, 3.5A power mains (non power-limited) power- limited LOW BATTERY SHUTDOWN 24VAC 12VDC + BAT -- -- DC + Outputs Outputs (4A max.) (1A max.) Supervised - Non power-limited 12VDC Rechargeable Battery (order separately) Note: Two (2) 12VDC rechargeable batteries...
- Page 5 Pole Mounting Using Optional Pole Mount Kit PMK2 (not included): Note: In order to properly mount ReServ5WP on a pole using Altronix PMK2, additional holes need to be drilled in the enclosure’s flanges, so the distance between those holes is 10”.
- Page 6 Notes: - 6 - ReServ5WP...
- Page 7 Notes: ReServ5WP - 7 -...
- Page 8 17.53” x 15.3” x 6.67” (445.3mm x 388.6mm x 169.4mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIReServ5WP...
