Shure Publications | User Guides | QLX-D
http://pubs.shure.com/guide/QLXD/en-US
Battery Installation
Accessing the Battery
Press the side tabs on the bodypack or unscrew the cover on the handheld
Compartment
as shown to access the battery compartment.
Installing Batteries
AA Batteries: Place batteries (note polarity markings) and AA Adaptor
as shown
Shure SB900 Battery: Place battery as shown (note polarity markings),
remove AA Adaptor from bodypack transmitter, stow AA Adaptor in
door for handheld transmitter
9/15/17, 2)49 PM
Page 21 of 51
