IR window Align with the receiver IR window during an IR sync for automated
transmitter programming.
Menu Navigation menu = Use to navigate between menu screens.
Buttons
▼
home screen display option.
enter = Press to confirm and save parameter changes.
Tip: Press the menu button to exit without saving parameter changes.
Battery Requires 2 AA batteries or a Shure SB900 rechargeable battery.
Compartment
AA Battery Adapter Secures batteries when powering transmitter with AA batteries instead of
Shure SB900 battery.
Bodypack Antenna For RF signal transmission.
Handheld Integrated For RF signal transmission.
Antenna
Microphone See Optional Accessories for a list of compatible cartridges.
Cartridge
TA4M Input Jack Connects to a 4-Pin Mini Connector (TA4F) microphone or instrument
cable.
Battery Contact Align the cover as shown to prevent reflections from the battery contacts
Cover during broadcasts or performances.
= Use to select menu screens, edit menu parameters, or choose a
