Turn on: The following potential sources of interference including other wireless systems,
computers, CD players, large LED panels, and effects processors to prevent selection of occupied
frequencies.
Scan and IR Sync
The simplest way to create an audio channel is to use the scan function to find the best available
receiver channel, and then use the IR sync feature to automatically tune the transmitter to the receiver
channel.
Step 1: Scanning to Find the Best Channel
The Scan function automatically selects the best available receiver channel.
1. Navigate to the Scan menu option.
2. Press enter to start the scan.
3. When the scan is complete, the channel will appear on the display.
Network Scan
The Network Scan feature automates frequency assignment by using a single receiver to scan and
deploy frequencies to all networked receiver within the same frequency band.
Network Scanning and Frequency Deployment
1. Connect receivers to an active Ethernet network. All receivers must be on the same subnet.
2. Prior to performing a network scan, turn on all receivers and allow 60 seconds for all receivers to
join the network.
3. Choose a group or custom group for deployment on the receiver that will be used to initiate the
network scan.
4. To start a network scan, press the menu button and navigate to the network scan menu. Press
enter.
5. When the scan is complete, the displays of receivers waiting for frequencies will flash.
6. Press enter to deploy the frequencies or press menu to cancel the deployment.
7. The front panel LEDs on each receiver will blink when a deployed frequency has been assigned.
Note: Full frequency deployment may not occur if the number of receivers in the network exceeds the number of
available frequencies in the selected group. Try another group or rescan after turning off unused receivers.
Step 2: IR Sync for Automatic Transmitter Set Up
Performing an IR Sync automatically tunes the transmitter to match the receiver frequency, forming a
wireless audio channel.
1. Turn on the transmitter.
2. Press the sync button on the receiver. The red ir LED will blink indicating that sync mode is active.
3. Align the IR sync windows of the transmitter and receiver at a distance of <15 cm (6 in.). When the
transmitter and receiver are aligned, the red ir LED remains on and the sync will automatically
occur.
