- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Shure BLX24E/PG58 o cerca il tuo prodotto tra le migliori offerte di Cuffie e Microfoni Wireless System Online user guide for Shure BLX wireless system. Version: 4 (2019-H)
-
Page 2: Table Of Contents
Shure Incorporated Table of Contents Tips to Improve Wireless System Performance BLXWireless System Getting Good Sound IMPORTANT SAFETY INSTRUCTIONS Correct Microphone Placement Wearing the Headworn Microphone System Components Adjusting Gain Quick Start Guide BLX1 Features BLX2 Front Panel Batteries Back Panel... -
Page 3: Blxwireless System
Shure Incorporated Wireless System IMPORTANT SAFETY INSTRUCTIONS READ these instructions. KEEP these instructions. HEED all warnings. FOLLOW all instructions. DO NOT use this apparatus near water. CLEAN ONLY with dry cloth. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accordance with the manufacturer’s instructions. -
Page 4: System Components
Shure Incorporated This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit. This symbol indicates that there are important operating and maintenance instructions in the literature accom panying this unit. WARNING: Danger of explosion if incorrect battery replaced. Operate only with AA batteries. - Page 5 Shure Incorporated Install batteries and turn on transmitter. On the transmitter, set the group and channel to match the receiver. The audio LED on the receiver should illu minate. If setting up additional systems, leave the first transmitter and receiver on. For each additional receiver, manual...
-
Page 6: Features
Shure Incorporated Features Front Panel BLX4 BLX88 ① audio LED Indicates strength of incoming audio signal: green for normal and red for overload. ② ready LED 6/28... -
Page 7: Back Panel
Shure Incorporated Green light indicates system is ready for use and receiving transmitter signal. ③ LED Display Displays group and channel setting. ④ group and channel Buttons Scan: Push and release group button to scan for an open group and channel. -
Page 8: Blx2
Shure Incorporated ③ 4-Pin Microphone Input Jack (TA4 connector) ④ Antenna ⑤ group Button Changes group setting. ⑥ LED Display Displays group and channel setting. ⑦ channel Button Changes channel setting. ⑧ Battery Compartment ⑨ Audio Gain Adjustment Rotate to increase or decrease transmitter gain. - Page 9 Shure Incorporated ④ channel Button Changes channel and gain setting. ⑤ LED Display Displays group and channel setting. ⑥ Identification Cap ⑦ Battery Compartment Transmitter LED Indicators LED Indicator Status Green Ready Rapidly Flashing Red Controls locked Solid Red Battery power low (less than 1 hour remaining*)
-
Page 10: Single System Set Up
Shure Incorporated Single System Set Up Before you begin, turn off all transmitters and turn on any equipment (other microphones or personal monitoring systems) that could cause interference during the performance. Press and release the group button on the receiver. -
Page 11: Multiple System Setup
Shure Incorporated Multiple System Setup Up to 12 systems can operate simultaneously (band and RF environment dependent). Important: Set up each system one-at-a-time. Once a receiver and transmitter are tuned to the same group and channel, leave the transmitter powered on. -
Page 12: Manually Setting Receiver Group And Channel
Shure Incorporated Manually Setting Receiver Group and Channel The receiver group may need to be changed as part of a multiple system setup. Group (letter) Hold the group button on the receiver until the display begins to flash. While the display is flashing, press the group button again to advance to the next group. -
Page 13: Getting Good Sound
Shure Incorporated Getting Good Sound Correct Microphone Placement • Hold the microphone within 12 inches from the sound source. For a warmer sound with increased bass presence, move the microphone closer. • Do not cover grille with hand. Wearing the Headworn Microphone •... -
Page 14: Adjusting Gain
Shure Incorporated Adjusting Gain Monitor the audio LED indicator on the receiver front panel when setting the transmitter gain. • Green: normal levels • Red: excessive sound levels (overload). The red LED should only illuminate infrequently when you speak loudly or play your instrument loudly. -
Page 15: Blx2
Shure Incorporated BLX2 The BLX2 features two gain level settings, default and attenuated (-10 dB). The default setting is used for most situations. If the receiver audio LED flickers red often, set the microphone to attenuated. Use the channel button to change the gain setting. -
Page 16: Wearing The Bodypack Transmitter
Shure Incorporated WARNING: Battery packs shall not be exposed to excessive heat such as sunshine, fire, or the like. Wearing the Bodypack Transmitter Clip the transmitter to a belt or slide a guitar strap through the transmitter clip as shown. -
Page 17: Power Off
Shure Incorporated Power Off Hold down the power button to power off the BLX2 or BLX4/88. To power off the BLX1, slide the power toggle switch to OFF. Removing and Installing Identification Caps The BLX2 is equipped with a black identification cap from the factory (dual vocal systems ship with additional gray cap). -
Page 18: Specifications
Shure Incorporated Issue Indicator Status Solution Make sure DC adapter is securely plugged into electrical Receiver LED screen off outlet. Make sure receiver is powered on. Transmitter indicator LED Replace transmitter batteries (see Changing Batteries). flashing red Change receiver and transmitter to a different group and/ or channel. - Page 19 Shure Incorporated Dynamic Range 100 dB, A-weighted, typical Operating Temperature -18°C (0°F) to 57°C (135°F) Note: Battery characteristics may limit this range. Polarity Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) pro duces positive voltage on pin 2 (with respect to pin 3 of lowimpedance output) and the tip of the high im...
- Page 20 Shure Incorporated -10dB -10 dBV maximum Gain Adjustment Range 10 dB RF Transmitter Output 10 mW, typical varies by region Dimensions 8.82 in. X 2.09 in. (224 mm X 53 mm) L x Dia. Weight 7.7 oz. (218 g) without batteries...
-
Page 21: Certifications
This product meets the Essential Requirements of all relevant European directives and is eligible for CE marking. Hereby, Shure Incorporated declares that the radio equipment is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.shure.com/europe/compliance... -
Page 22: Important Product Information
Licensing of Shure wireless microphone equipment is the user’s responsibility, and licensability de pends on the user’s classification and application, and on the selected frequency. Shure strongly urges the user to contact the appropriate telecommunications authority concerning proper licensing, and before choosing and ordering frequencies. -
Page 23: Australia Warning For Wireless
Shure Incorporated 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Industry Canada ICES-003 Compliance Label: CAN ICES-3 (B)/NMB-3(B) Note: EMC conformance testing is based on the use of supplied and recommended cable types. The use of other cable types may degrade EMC perfor... -
Page 24: Frequencies For European Countries
Shure Incorporated Band Range Output Power 742 to 766 MHz 10 mW 794 to 806 MHz 10 mW 823 to 832 MHz 10 mW 863 to 865 MHz 10 mW Note: Frequency bands might not be available for sale or authorized for use in all countries or regions. - Page 25 Shure Incorporated Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich F, GB, GR, H, I, IRL, L, LT 606 - 630 MHz* NL, P, PL, S, SK, SLO...
- Page 26 Shure Incorporated K14 614-638 MHz Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich A, B, BG, CH, CY, CZ, D, EST 614 - 638 MHz*...
- Page 27 Shure Incorporated R12 796-806 MHz Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich 796 - 806 MHz* A, B, BG, CH, CY, CZ, D, DK, E, EST...
- Page 28 Shure Incorporated T11 863-865 MHz Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich A, B, BG, CH, CY, CZ, D, DK, E, EST license free...
