QLX-D
Wireless System
Shure QLXD wireless system user guide. Includes dimensions, frequency bands, error codes, and more.
Version: 5.1 (2020-H)

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the QLXD14E/98H-H51 and is the answer not in the manual?

Questions and answers

Summary of Contents for Shure QLXD14E/98H-H51

  • Page 1 QLX-D Wireless System Shure QLXD wireless system user guide. Includes dimensions, frequency bands, error codes, and more. Version: 5.1 (2020-H)
  • Page 2: Table Of Contents

    Step 3: Install Batteries into Transmitter Shure AXT600 Spectrum Manager Compatibility Step 4: IR Sync to Create an Audio Channel Using QLX-D with a Shure ULX-D System Step 5: Sound Check and Gain Adjustment Setting Regional TV Channel Spacing Custom Groups...
  • Page 3 Shure Incorporated Downloading and Updating Firmware QLXD4 Updating the Receiver QLXD1 Updating the Transmitter QLXD2 Receiver Output Connectors Troubleshooting TA4M Input Connector Diagram Error Codes and Solutions Frequency Range and Transmitter Output Power Single and Dual Rackmount Assembly Frequencies for European Countries...
  • Page 4: Qlx-D Wireless System

    Shure Incorporated QLX-D   Wireless System IMPORTANT SAFETY INSTRUCTIONS READ these instructions. KEEP these instructions. HEED all warnings. FOLLOW all instructions. DO NOT use this apparatus near water. CLEAN ONLY with dry cloth. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accordance with the manufacturer’s instructions.
  • Page 5: Warning

    Important Product Information LICENSING INFORMATION Licensing: A ministerial license to operate this equipment may be required in certain areas. Consult your national authority for possible requirements. Changes or modifications not expressly approved by Shure Incorporated could void your authority to 5/66...
  • Page 6: Information To The User

    Automatic channel scan and IR sync make finding and assigning an open frequency quick and easy. ® Ethernet connection provides networked channel scanning across multiple receivers and Shure Wireless Workbench control software compatibility for advanced frequency coordination. AES-256 encryption comes standard and can be easily enabled for secure wireless transmission.
  • Page 7: Features

    • Compatible with external control systems such as AMX or Crestron • Professional-grade all-metal construction • Transmitters use 2 AA batteries or Shure SB900 rechargeable battery System Components ① QLXD4 Receiver ② PS24 Power Supply ③ 1/2 Wave Antennas (2) ④...
  • Page 8: Model Variations

    MX153 (black or tan) • SM35 Zipper Bag Bodypack and Handheld Combo System • QLXD1 bodypack transmitter with WL185 Microflex cardioid lavalier microphone • QLXD2 handheld transmitter with Shure SM58 microphone cartridge • Battery Contact Cover • Zipper Bag (2) 8/66...
  • Page 9: Quick Start

    Shure Incorporated Quick Start Step 1: Power and Antenna Connection ① Connect an antenna to each of the antenna connectors. ② Connect the power supply to the receiver and plug into an AC power source. ③ Connect the receiver audio output to a mixer or amplifier.
  • Page 10 Shure Incorporated 2. Press the enter button to start a frequency scan. The scan icon will flash while in scan mode. When the scan is com­ plete, the selected group and channel appear on the display. 10/66...
  • Page 11: Step 3: Install Batteries Into Transmitter

    AA Batteries: Place batteries (note polarity markings) and AA Adaptor as shown ◦ Shure SB900 Battery: Place battery as shown (note polarity markings), remove AA Adaptor from bodypack transmitter, stow AA Adaptor in door for handheld transmitter Note: If using AA batteries, select a battery type from the transmitter menu to ensure accurate battery metering.
  • Page 12: Step 5: Sound Check And Gain Adjustment

    Shure Incorporated sync good appears on the display when IR sync is complete. The blue rf LED will illuminate indicating that the transmit­ ter is within range of the receiver. Note: If the IR sync fails, repeat the IR sync procedure, carefully maintaining alignment between the IR windows of the transmitter and receiver.
  • Page 13: Hardware Interface

    Shure Incorporated Hardware Interface Receiver Front and Back Panels ① Display Shows menu options, receiver and transmitter settings. 13/66...
  • Page 14 Shure Incorporated ② Arrow Buttons Adjust gain setting or change menu parameters. ③ Enter Button Press to save menu or parameter changes. ④ Sync Button Press to activate IR sync. ⑤ Power Switch Powers receiver on or off. ⑥ Audio LED ◦...
  • Page 15 Shure Incorporated ⑪ Power Cord Strain Relief Secures power cord. ⑫ Power Supply Jack Connection point for DC power supply. ⑬ Ethernet Port For network connection. ◦ Amber LED (network speed): off = 10 Mbps, on = 100 Mbps ◦...
  • Page 16: Receiver Display

    Shure Incorporated Press to restore receiver default settings. ⑮ Antenna Connectors BNC connector for receiver antennas ⑯ Mic/Line Switch Sets output level to microphone or line. ⑰ XLR Audio Output Balanced (1: ground, 2: audio +, 3: audio - ) ⑱...
  • Page 17: Navigating The Receiver Menus

    Enable the Low Battery Alert to flash the receiver display when battery runtime is less than 30 minutes. ⑮ SB900 Battery Runtime When the transmitter is powered by a Shure SB900 rechargeable battery, remaining runtime is displayed in hours:minutes. Navigating the Receiver Menus The receiver has a main menu for setup and configuration and an advanced menu to access additional receiver functions.
  • Page 18 Shure Incorporated ① Scan Receiver automatically scans for the best available frequency ② Network Scan Scans to find frequencies for networked receivers operating in the same frequency band (available when connected to a network with receivers in the same band) ③...
  • Page 19 Shure Incorporated ① Custom Groups Use to add channels and frequencies to Custom Groups ② TV Channel Spacing Selects the regional bandwidth for TV channel display ③ Low Battery Alert Enable or disable the low battery alert on the receiver screen ④...
  • Page 20: Transmitters

    Shure Incorporated ⑦ Network Reset Returns network settings and IP address to default setting ⑧ Factory Reset Restores factory settings For application and configuration details, see the related guide topic for each advanced feature. Tips for Editing Menu Parameters •...
  • Page 21: Transmitter Display

    ⑥ Battery Compartment Requires 2 AA batteries or a Shure SB900 rechargeable battery. ⑦ AA Battery Adapter Secures batteries when powering transmitter with AA batteries instead of Shure SB900 battery. ⑧ Bodypack Antenna For RF signal transmission. ⑨ Handheld Integrated Antenna For RF signal transmission.
  • Page 22: Transmitter Controls

    Shure Incorporated Group and Channel SB900 battery runtime Frequency ③ Encryption Status Icon displayed when encryption is enabled. ④ Lock Displayed when transmitter controls are locked. ⑤ RF Power RF power setting (Lo or Hi). ⑥ Mic Offset Displays mic offset level in 3 dB increments.
  • Page 23: Transmitter Menu Options And Navigation

    Shure Incorporated Bodypack Handheld Transmitter Menu Options and Navigation The transmitter features individual menu screens for setting up and adjusting the transmitter. To access the menu options from the home screen, press the menu button. Each additional press of the menu button advances to the next menu screen.
  • Page 24 ⑧ battery type Use to set the battery type to match the installed AA battery type to ensure accurate battery metering. Menu is not dis­ played when Shure SB900 batteries are installed. Tips for Editing Menu Parameters • To access the menu options from the home screen, press the menu button. Each additional press of the menu button ad­...
  • Page 25: Control Lock Options For The Receiver And Transmitter

    Shure Incorporated Control Lock Options for the Receiver and Transmitter Control lock options are available for both the receiver and the transmitter to protect against accidental or unauthorized changes. Locks can be directly set from the component menu, or remotely set from WWB6. To maintain protection, controls re­ main locked when the transmitter is turned off and turned on.
  • Page 26: Battery Installation

    Shure Incorporated Battery Installation ① Accessing the Battery Compartment Press the side tabs on the bodypack or unscrew the cover on the handheld as shown to access the battery compartment. 26/66...
  • Page 27: Setting The Aa Battery Type

    To ensure accurate display of transmitter runtime, set the battery type in the transmitter menu to match the installed AA battery type. If a Shure SB900 rechargeable battery is installed, selecting a battery type is not necessary and the battery type menu will not be displayed.
  • Page 28: Shure Sb900 Rechargeable Battery

    Shure Incorporated Shure SB900 Rechargeable Battery Shure SB900 lithium-ion batteries offer a rechargeable option for powering the QLX-D transmitters. Batteries quickly charge to 50% capacity in one hour and reach full charge within three hours. Single chargers and multiple bay chargers are available to recharge the Shure batteries.
  • Page 29: Important Tips For Care And Storage Of Shure Rechargeable Batteries

    Fault: check connections and battery No battery in bay Important Tips for Care and Storage of Shure Rechargeable Batteries Proper care and storage of Shure batteries results in reliable performance and ensures a long lifetime. • Always store batteries and transmitters at room temperature •...
  • Page 30: Low Battery Alert

    Shure Incorporated • During storage, check batteries every 6 months and recharge to 40% of capacity as needed Low Battery Alert The receiver display can be configured to flash when the battery runtime for a transmitter is less than 30 minutes.
  • Page 31: Audio Signal Encryption

    Shure Incorporated From the receiver home screen, use the arrow buttons to increase or decrease the gain: • A single button press adjusts the gain in 1 dB increments • Press and hold the button for larger adjustments Test the transmitter at performance levels when adjusting the gain. Monitor the audio meter and the audio LED to prevent over­...
  • Page 32: Removing Encryption

    Shure Incorporated Removing Encryption Press the menu button to navigate to the encryption menu. Select OFF. Press enter to save. IR sync the transmitter and receiver to clear the encryption key from the transmitter and prevent an encryption key mis­ match between components, indicated by a FAIL message. Note: If encryption has been set from off to on, the receiver will generate a new encryption key and must be IR synced to the transmitter to share the new key.
  • Page 33: Scan And Ir Sync

    Shure Incorporated Important: Before you begin a scan or frequency assignment: • Turn off: All transmitters for system you are setting up to prevent interference with frequency scans. • Turn on: The following potential sources of interference including other wireless systems, computers, CD players, large LED panels, and effects processors to prevent selection of occupied frequencies.
  • Page 34: Manual Group And Channel Assignment

    Shure Incorporated sync good appears on the display when IR sync is complete. The blue rf LED will illuminate indicating that the transmit­ ter is within range of the receiver. Note: If the IR sync fails, repeat the IR sync procedure, carefully maintaining alignment between the IR windows of the transmitter and receiver.
  • Page 35: Manual Frequency Selection

    Shure Incorporated Manual Frequency Selection Manual frequency selection can be used instead of groups and channels to set the transmitter and receiver to a specific fre­ quency. For example, an audio channel can be created by setting the receiver and transmitter to same frequency. Setting the Receiver Frequency Press menu to navigate to the frequency setting option. Use the arrow buttons to adjust the frequency. Press and hold for faster scrolling.
  • Page 36: Radio Frequency (Rf) Settings

    Shure Incorporated Matching Audio Levels with Mic Offset When linking two transmitters to a receiver, there may be a difference in volume levels between microphones or instruments. If this occurs, use the Mic Offset function to match the audio levels and eliminate audible volume differences between transmit­ ters. If using a single transmitter, set Mic Offset to 0 dB.
  • Page 37: Shure Axt600 Spectrum Manager Compatibility

    Compatible Frequency List can be deployed and monitored by the Spectrum Manager. For more information regarding the Spectrum Manager, see the Axient System Guide. Using QLX-D with a Shure ULX-D System Transmitters and receivers from QLX-D and ULX-D component groups can be paired to form audio channels.
  • Page 38: Setting Regional Tv Channel Spacing

    Shure Incorporated Align the transmitter IR window with the receiver to send the presets to the transmitter. Important: All QLX-D and ULX-D components must use 2.0 firmware or greater for proper functionality. Setting Regional TV Channel Spacing The parameter for TV channel spacing allows the receiver to match regional TV bandwidth usage and accurately display local TV channels.
  • Page 39: Custom Groups

    Shure Incorporated Custom Groups Specific channels and frequencies can be selected and placed into custom groups. Custom groups are commonly used to as­ sign networked receivers to a specific range of frequencies or to pre-configure receivers for rental applications. Once a custom group has been created, it can be loaded to the receiver using the group menu. When network scan is used to assign frequencies from a receiver with a custom group selected, all of custom groups (U1, U2, U3, etc...) from that receiver will be loaded to all other receivers on the network.
  • Page 40 Shure Incorporated The receiver has 6 custom groups available named U1, U2, U3, U4, U5, and U6. Press menu while holding the enter button to access the Custom Group screen. Selecting A Custom Group Press enter to enable editing of a group (indicated by the group flashing).
  • Page 41: Networking

    Use shielded Cat 5 or better Ethernet cables to ensure reliable network performance • The LEDs on the Ethernet port illuminate indicating a network connection is active • The network icon illuminates when the receiver detects additional Shure devices on the network • All components must operate on the same subnet •...
  • Page 42: Setting The Ip Address And Subnet Mask Manually

    Shure Incorporated Setting the IP Address and Subnet Mask Manually IP addresses and subnet masks can be manually set from the advanced menu in the receiver or from the monitor panel in Wireless Workbench 6. Network settings entered manually must be valid and conform to IP protocols to ensure proper network communication.
  • Page 43: Connecting To An External Control System

    Connecting to an External Control System The receiver connects to external controls systems (AMX or Crestron) via Ethernet cables. • Connection: Ethernet (TCP/IP; QLXD receiver is the client) • Port: 2202 Managing Your System with Shure Software Wireless Workbench Manage every facet of wireless system performance, from pre­show planning to live channel monitoring, with Wireless Work­ bench. • Visit the Wireless Workbench page to download Workbench.
  • Page 44: Firmware Versioning

    (including transmitters), must have the same MAJOR and MINOR firmware version numbers (e.g., 1.2.x). Downloading and Updating Firmware A free Shure Update Utility tool is available by visiting www.shure.com. The Shure Update Utility is also bundled with Shure Wireless Workbench software.
  • Page 45: Troubleshooting

    Shure Incorporated The receiver displays the type of transmitter firmware it has available. The receiver holds one type of firmware at a time. ◦ HH BP = handheld or bodypack firmware ◦ BN GN = gooseneck or boundary firmware Press enter to start the update.
  • Page 46 Shure Incorporated Make sure that the receiver and transmitter are receiving sufficient voltage. Check the battery indicators. Replace or recharge the batteries if necessary. Gain Adjust the system gain on the front of the receiver. Ensure the mic/line switch setting (XLR output only) on the back of the re­ ceiver corresponds to the input of the mixing console, amplifier, or processor.
  • Page 47: Increasing Range

    Err.006 No Frequencies Found Rescan, select a different group, or use WWB to find a frequency. Use the Shure Update Utility to update the unit to the latest firmware. Err.007 Firmware Version Self-Test Failed If the error persists contact Shure support.
  • Page 48: Single And Dual Rackmount Assembly

    Shure Incorporated Error Description Solutions Code To complete the firmware update, match the type of transmitter to the type of firmware the receiver currently has. Err.009 Transmitter Type Mismatch HH BP = handheld or bodypack firmware BN GN = gooseneck or boundary firmware...
  • Page 49: Securing The Ac Power Cord

    Shure Incorporated Securing the AC Power Cord Installing Footpads 49/66...
  • Page 50: Accessories

    Shure Incorporated Accessories Optional Accessories Batteries and Chargers Shure Lithium-Ion Rechargeable Battery SB900 8-Bay Shure Battery Charger SBC800-US Dual Docking Charger With PS45US Power Supply SBC200-US Dual Docking Charger, Power Supply Not Included SBC200 2-Bay networked docking charger SBC220 Single Battery Charger...
  • Page 51: Cables And Connectors

    Shure Incorporated UABIAST-E UABIAST-CHN UABIAST-K UABIAST-J UABIAST-AZ UABIAST-TW In-Line Amplifiers and Antennas In-Line Antenna Amplifier, 174-216 MHz UA834V In-Line Antenna Amplifier, 470-902 MHz UA834WB In-Line Antenna Amplifier, 902-960 MHz UA834XA Active Directional Antenna 470-790MHZ UA874E Active Directional Antenna 470-698MHZ UA874US...
  • Page 52 774-865 MHz UA8-774-865 00-1000 MHz UA8-900-1000 Hardware, Cases, and Accessories Hard Carrying Case For SLX System WA610 Mute Switch for Shure Handheld Transmitters UAMS/BK Cable, Instrument, 2.5 foot (.75 m), 4 Pin Mini Connector WA302 (TA4F) to 1/4-inch Connector. 52/66...
  • Page 53: Specifications

    Premium Guitar Cable TQG Threaded Connector WA305 Premium Guitar Cable TQG Latching Connector WA306 Cable, Microphone, 4-foot (1.3m), 4-pin Mini Connector (TA4F) to XLR Connector (F), used with Shure Bodypack WA310 Transmitters. In-line audio mute switch for Shure wireless bodypack WA360 transmitters with a TA4F connector.
  • Page 54: Battery Life

    Shure Incorporated >120 dB, A-weighted, typical Total Harmonic Distortion −12 dBFS input, System Gain @ +10 <0.1% System Audio Polarity Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3 of XLR output) and the tip of the 6.35 mm (1/4-inch) output.
  • Page 55: Audio Output

    Shure Incorporated Connector Type Impedance 50 Ω Audio Output Gain Adjustment Range -18 to +42 dB in 1 dB steps Configuration 1/4" (6.35 mm) Impedance balanced (Tip=audio, Ring=no audio, Sleeve=ground) balanced (1=ground, 2=audio +, 3=audio −) Impedance 1/4" (6.35 mm) 100 Ω (50 Ω Unbalanced) 100 Ω Full Scale Output 1/4"...
  • Page 56: Audio Input

    Shure Incorporated Battery Type Shure SB900 Rechargeable Li-Ion or AA batteries 1.5 V Dimensions 86 mm x 65 mm x 23 mm (3.38in. x 2.57 in. x 0.92 in.) H x W x D , without antenna Weight 138 g (4.9 oz.), without batteries Housing Cast aluminum...
  • Page 57: Qlxd2

    1 mW or 10 mW QLXD2 Mic Offset Range 0 to 21 dB (in 3 dB steps) Battery Type Shure SB900 Rechargeable Li-Ion or AA batteries 1.5 V Dimensions 269 mm x 51 mm (10.6 in. x 2.0 in.) L x Dia. Weight 307 g (12.1 oz.), without batteries...
  • Page 58: Receiver Output Connectors

    Shure Incorporated Receiver Output Connectors 58/66...
  • Page 59: Ta4M Input Connector Diagram

    Shure Incorporated TA4M Input Connector Diagram ① Ground ② Bias Voltage ③ Audio Input ④ Ground 59/66...
  • Page 60: Frequency Range And Transmitter Output Power

    Shure Incorporated Frequency Range and Transmitter Output Power Power ( mW RMS )* Band Frequency Range (MHz) (Lo/Nm/Hi) 470 to 534 1 / 10 470 to 534 1 / 10 479 to 534 1 / 10 510 to 530 1 / 10...
  • Page 61: Frequencies For European Countries

    Shure Incorporated Power ( mW RMS )* Band Frequency Range (MHz) (Lo/Nm/Hi) 902 to 928 (All Americas except Brazil) 1 / 10 902 to 907.500, 915 to 928 (Brazil) 1 / 10 915 to 928 (Australia) 1 / 10 1492 to 1525...
  • Page 62 Shure Incorporated H51 534-598 MHz Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich A, B, BG, CH, CY, CZ, D, EST 534 - 598 MHz*...
  • Page 63 Shure Incorporated L52 632-694 MHz Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich A, B, BG, CH, CY, CZ, D, DK, EST, F FIN, GB, GR, H, HR, I, IRL, IS, L, LT...
  • Page 64 Shure Incorporated Q51 794-806 MHz Country Code Frequency Range Code de Pays Gamme de frequences Codice di paese Gamme di frequenza Código de país Gama de frequencias Länder-Kürzel Frequenzbereich A, B, BG, CH, CY, CZ, D, DK, E, EST F, FIN, GB, GR, H, HR, I, IRL, IS, L, LT...
  • Page 65: Certifications

    Note: Please follow your regional recycling scheme for batteries and electronic waste Hereby, Shure Incorporated declares that the radio equipment is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.shure.com/europe/compliance...
  • Page 66: Qlxd4

    Shure Incorporated QLXD4 Approved under the Declaration of Conformity (DoC) provision of FCC Part 15. Conforms to electrical safety requirements based on IEC 60065. 66/66...
