Installer's Guide

When using multiple monitors on 1 system;
Master / Slave Setting
Only the 1 handset set as the MASTER will display an image when the door station is activated.
All other monitors will ring, and will display the image once the 'Talk' button is pressed.
In the event of no video
A That the system is powered sufficiently.
or audio signals coming
B Each monitor needs to be set to a MASTER or SLAVE position
from the monitor, or if the
C All system cabling is secured and properly connected.
call button or audio cannot
D All system cabling is clear of breaks or short circuits.
be activated on the door
E Bench test the system if the issue cannot be found.
station, check the following;
A The user instructions and operation of the monitor has been understood.
In the event of a lock
B That the lock is powered sufficiently.
release issue,
C All system cabling is secured and properly connected.
check the following;
D All system cabling is clear of breaks or short circuits.
E On the rear of the door station, ensure the lock output is switching when activated by the monitor.
11
