4.4.2 Method of Parameter Setting

■ Input method of numeric data
Example 1: Change the span from 100m
The setting mode can be changed referring 5.3 parameter list
SHIFT INC
Press " SET " key.
SHIFT INC
Press " SET " key.
SHIFT INC
Press " SHIFT " key any time.
SHIFT INC
Press " INC " key any time.
SHIFT INC
Press " SET " key.
3 /h to 150m
Indication of % flow
rate.
SET
Enter to the setting
mode.
(Span number is
" B10 ")
SET
Enter to data number
item.
SET
Move the position to
input the data.
SET
Set " 5 " and indicate
3
" 150m /h ".
SET
3 /h
SHIFT
SHIFT
SHIFT
IMPORTANT
After setting a parameter, keep the power on for at
least 30 seconds.
If the power of flowmeter is turned off, a parameter
setting is released.
4-7
4. BASIC OPERATING PROCEDURES
Ensure the setting
data.
SET
INC
Press " SET " key.
Complete the Setting.
SET
INC
Press " SET " and " SHIFT " key.
Return to display
mode.
SET
INC
IM 01F06A00-01E
F040402.EPS
