MC 5M - MC 6P - MC 7P -
Instructions for use
107141543 G - EN DE FR NL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC 5M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nilfisk-Advance MC 5M

Summary of Contents for Nilfisk-Advance MC 5M

  • Page 1 MC 5M - MC 6P - MC 7P - Instructions for use 107141543 G - EN DE FR NL...

  • Page 2: Table Of Contents

    MC 5M - MC 6P - MC 7P Contents Symbols used to mark instructions .....................4 Safety instructions ......................4 Description.........................5 Use per day ..........................5 Purpose ...........................5 Operating elements .........................6 Before starting the cleaner ....................7 Setting up the cleaner ......................7 Check the oil level ........................7 Fill up detergent tank ......................8...

  • Page 3: Symbols Used To Mark Instructions

    MC 5M - MC 6P - MC 7P Symbols used to mark instructions Safety instructions in these This indicates tips and instruc- operating instructions which tions to simplify work and to en- must be observed to prevent sure safe operation.

  • Page 4: Description

    MC 5M - MC 6P - MC 7P 2 Description Use per day We recommend these products for an optional use of approx. X-hours use per day. MC 5M Hours use per day Recommended for use x hours / day...

  • Page 5: Operating Elements

    MC 5M - MC 6P - MC 7P Operating elements 1. Push/pull handle 2. Spray gun 3. Electrical lead 4. Holder for high pressure hose 5. High-pressure hose 6. Fastening screw 7. Lance 8. Parking brake 9. High-pressure hose connection (on standard models without hose reel) 10.

  • Page 6: Before Starting The Cleaner

    MC 5M - MC 6P - MC 7P 3 Before starting the cleaner Setting up the cleaner CAUTION! Never lift the cleaner alone. Always ask a second person to help. 1. Before using the cleaner for the first time, check it care- fully to detect any faults or damage.

  • Page 7: Connecting The High Pressure Hose

    MC 5M - MC 6P - MC 7P Fill up detergent tank 1. Fill up detergent tank with prediluted Nilfisk detergent. 2. Pull detergent hose and filter out of the storage and put it through the opening of the detergent tank filler cap.

  • Page 8: Electrical Connection

    MC 5M - MC 6P - MC 7P NOTE! In the case of poor water quality We recommend the use of a tex- (sand, etc.), we recommend that tile-reinforced water hose with a a fine water filter is fitted to the nominal diameter of min.

  • Page 9: Ba Valve

    MC 5M - MC 6P - MC 7P BA valve This high pressure washer/cleaner is only allowed to be con- nected with the drinking water mains, when an appropriate backflow preventer has been installed, Type BA according to EN 60335-2-79.

  • Page 10: Control / Operation

    MC 5M - MC 6P - MC 7P 4 Control / Operation Connecting the spray 1. Pull back the blue quick- lance to the spray gun release grip (A) of the spray gun. 2. Insert the nipple of the spray...
  • Page 11 MC 5M - MC 6P - MC 7P 4.2.1 Switching on the 1. Before connecting the cleaner when it is suction set: 61256 to the connected to open cleaner, fill the hose with tanks in suction mode water. (Pressure activated model) 2.

  • Page 12: Pressure Regulation With Tornado Plus Lance And Powerspeedvario Plus Lance

    MC 5M - MC 6P - MC 7P Pressure regulation 1. Turn the twist grip on the with Tornado Plus lance: lance and PowerSpeedVario Plus – High pressure = lance. clockwise (+) – Low pressure = anticlockwise (–) 1. Twist cap of the FlexoPower-...

  • Page 13: Lifting With Crane

    MC 5M - MC 6P - MC 7P Lifting with crane 1. Before crane lifting the machine should be in balance. Loosen the screw (A), push the handle (B) a little forward. 2. When the two marks are aligned (C), the handle is in crane-lifting -position.

  • Page 14: Applications And Methods

    MC 5M - MC 6P - MC 7P 5 Applications and methods Techniques Efficient high pressure cleaning is achieved by following a few guidelines, combined with your own personal experience of specific cleaning tasks. Accessories and detergents, when correctly chosen, can increase the efficiency of your pressure washer.

  • Page 15: Some Typical Cleaning Tasks

    MC 5M - MC 6P - MC 7P Some typical cleaning tasks 5.2.1 Agriculture Task Accessories Method Stables Chemical Foam 1. Soaking – apply foam to all surfaces (bottom to top) Pig Pens, Sties Injectors and wait for approx. 10 - 30 minutes.
  • Page 16 MC 5M - MC 6P - MC 7P 5.2.3 Buildings and Equipment Task Accessories Method General surfaces Foam injectors 1. Apply thick foam over the surfaces to be cleaned. Standard lance Apply on dry surfaces. Apply from top to bottom on...

  • Page 17: After Using The Cleaner

    MC 5M - MC 6P - MC 7P 6 After using the cleaner Switching off the 1. Turn the main switch to posi- cleaner tion „OFF“. 2. Close water tap. 3. Squeeze the spray gun han- dle until the cleaner is de- pressurised.

  • Page 18: Storing The Cleaner (Below 0°C)

    MC 5M - MC 6P - MC 7P 2. At last turn, lock the cable end in the cable lock (C). Storing the cleaner Store the cleaner in a dry room without danger of frost or protect as (below 0°C)

  • Page 19: Maintenance

    MC 5M - MC 6P - MC 7P 7 Maintenance Maintenance plan First time Every 500 after 50 Weekly operating As required operating hours hours 7.2.1 Cleaning water inlet fi lter 7.2.2 Checking pump oil level 7.2.3 Changing pump oil First change - and 7.2.4...
  • Page 20 MC 5M - MC 6P - MC 7P 2. If necessary, add oil. Fill to MAX level (B). 7.2.3 Changing the pump oil 1. Before changing the oil, al- low the cleaner to become warm. 2. Remove cabinet. 3. Loosen and remove drain plug (C).The plug magnet has...

  • Page 21: Troubleshooting

    MC 5M - MC 6P - MC 7P 8 Troubleshooting Fault Cause Remedy Pressure drop • Air in the system • Vent the system by operating the spray gun several times at short intervals. If necessary, operate the cleaner for a short time without the high- pressure hose connected.

  • Page 22: Further Information

    MC 5M - MC 6P - MC 7P Fault Cause Remedy No detergents drawn in • Detergent tank empty • Top up detergent tank • The cap on the FlexoPower- • Set to low pressure Plus nozzle head is not set to low pressure •...

  • Page 23: Specifications

    Specifications 5M-180/840 5M-180/840 XT 5M-200/1000 5M-200/1000 XT V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz кВт bar (MPa) Бар (МПа) 180 (18) 180 (18) 200 (20) 200 (20) 巴（兆帕） л/час 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25) 250 (25) 巴（兆帕）...
  • Page 24 Specifications 5M-200/1050 FA 5M-200/1050 5M-200/1050 XT 5M-220/1130 FA V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz кВт bar (MPa) Бар (МПа) 200 (20) 200 (20) 200 (20) 220 (22) 巴（兆帕） л/час 1040 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25) 250 (25) 巴（兆帕）...
  • Page 25 Specifications 5M-220/1130 5M-220/1130 XT 5M-170/980 5M-170/980 V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 200V/3ph/50Hz 200V/3ph/60Hz кВт bar (MPa) Бар (МПа) 220 (22) 220 (22) 170 (17) 170 (17) 巴（兆帕） л/час 1040 1040 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25) 250 (25) 巴（兆帕）...
  • Page 26 Specifications 5M-200/1050 5M-200/1050 XT 5M-100/770 5M-100/770 XT NO,BE NO,BE 230/400V/ 230/400V/ V/ph/Hz 230V/1ph/50Hz 230V/1ph/50Hz 3ph/50Hz 3ph/50Hz кВт bar (MPa) Бар (МПа) 200 (20) 200 (20) 100 (10) 100 (10) 巴（兆帕） л/час 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 150 (15) 150 (15) 巴（兆帕）...
  • Page 27 Specifications 5M-200/1050 5M-220/1130 6P-250/1100 FA 6P-250/1100 FA 220/440V/ 220/440V/ 400V 220/440V V/ph/Hz 3ph/60Hz 3ph/60Hz 3ph/50Hz 3ph/60Hz кВт bar (MPa) Бар (МПа) 200 (20) 220 (22) 250 (25) 250 (25) 巴（兆帕） л/час 1040 1000 1000 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25) 250 (25)
  • Page 28 Specifications 6P-250/1100 6P-180/1300 FA 6P-180/1300 FA 6P-170/1600 FA FAXT 400V 220/440V 400V V/ph/Hz 400V/3ph/50Hz 3ph/50Hz 3ph/60Hz 3ph/50Hz кВт bar (MPa) Бар (МПа) 180 (18) 180 (18) 170 (17) 250 (25) 巴（兆帕） л/час 1200 1200 1500 1000 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25)
  • Page 29 Specifications 6P-180/1300 6P-180/1300 6P-170/1600 6P-200/1100 FAXT FAXT FAXT FAXT NO,BE 230/400V V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 3ph/50Hz кВт bar (MPa) Бар (МПа) 180 (18) 180 (18) 170 (17) 200 (20) 巴（兆帕） л/час 1200 1200 1500 1000 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25)
  • Page 30 Specifications 6P-100/1600 7P-195/1280 7P-195/1280 FA 7P-195/1280 FA FAXT EU,DK V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz кВт bar (MPa) Бар (МПа) 100 (10) 195 (19,5) 195 (19,5) 195 (19,5) 巴（兆帕） л/час 1500 1180 1180 1180 升/小时 bar (MPa) Бар (МПа) 150 (15) 250 (25) 250 (25) 250 (25)
  • Page 31 Specifications 7P-195/1280 7P-195/1280 7P-195/1280 FA 7P-195/1280 FA FBFA 200V 200V V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 3ph/50Hz 3ph/60Hz кВт bar (MPa) Бар (МПа) 195 (19,5) 195 (19,5) 195 (19,5) 195 (19,5) 巴（兆帕） л/час 1180 1180 1180 1180 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 250 (25) 250 (25)
  • Page 32 Specifications 7P-195/1280 FA 7P-195/1280 FA NO, BE 230/400V 220/440V V/ph/Hz 3ph/50Hz 3ph/60Hz кВт bar (MPa) Бар (МПа) 195 (19,5) 195 (19,5) 巴（兆帕） л/час 1180 1180 升/小时 bar (MPa) Бар (МПа) 250 (25) 250 (25) 巴（兆帕） 1280 1280 °C (°F) 85 (185) 85 (185) bar (MPa) Бар...
  • Page 33 EN: Country variant. DE: Ländervarianten. FR: Selon le pays. NL: Na- tionale variant. IT: Variante per il Paese. NO: Variant i ulike land. SV: Landsvariant. DA: Landespecifik variant. FI: Maakohtainen vaihtelu. ES: Depende del país. PT: Variante do país. EL: Έκδοση χώρας. TR: Ülke- deki model.
  • Page 34 EN: Max. water pressure. DE: Max Wasserdruck. FR: Pression d‘eau maximale. NL: Max. waterdruk. IT: Max. pressione dell‘acqua. NO: Maks. vanntrykk. SV: Max vattentryck. DA: Max. vandtryk. FI: Suurin (MPa) vedenpaine. ES: Presión máxima de entrada del agua. PT: Pressão máxima de água.
  • Page 35 EN: Max dry suction height. DE: Max. Trockensaughöhe. FR: Hauteur d‘aspiration à sec max. NL: Max. droge aanzuighoogte. IT: Altezza massima di aspirazione secco. NO: Maks. sugehøyde tørr. SV: Max torr- sugningshöjd. DA: Maks. sugehøjde, tør. FI: Suurin kuivaimukorkeus. ES: Altura máxima de succión en seco. PT: Altura de aspiração a seco máx.
  • Page 36 EN: Vibration. DE: Vibrationen FR: Vibration NL: Vibratie IT: Vibrazioni NO: Vibrasjoner SV: Vibration DA: Vibration FI: Tärinäarvot ES: Vibra- (ISO 5349 a ción PT: Vibrações EL: Δόνηση TR: Titreşimi SL: Vibracije. HR: Vibracije. 米/秒² SK: Vibrácie. CS: Vibrace PL: Drgania HU: Vibráció RO: Vibraţii BG: Вибрации.
  • Page 37 HEAD QUARTER GERMANY PERU TURKEY Nilfi sk GmbH Nilfi sk S.A.C. Nilfi sk A.S. DENMARK Guido-Oberdorfer-Straße 2-10 Calle Boulevard 162, Of. 703, Lima 33- Serifali Mh. Bayraktar Bulv. Sehit Sk. No:7 Nilfi sk A/S 89287 Bellenberg Perú Ümraniye, 34775 Istanbul Kornmarksvej 1 Tel.: (+49) (0)7306/72-444 Lima...
