1.

Introduction

1.1

Features

• ATSAMC21N18A microcontroller
• Embedded Debugger
– USB interface
– Auto-ID for board identification in Atmel Studio
– One yellow status LED
– One green board power LED
– Symbolic debug of complex data types icluding scope information
– Programming and debugging of on-board SAMC21N through Serial Wire Debug (SWD)
– Data Gateway Interface: SPI, I
– Virtual COM port (CDC)
– Control of on-board power switch to protect connected extensions against high voltage
• Digital I/O
– Two mechanical buttons (user and reset button)
– One QTouch
– One yellow user LED
– Three Xplained Pro extension headers
• Two selectable target voltages
– 3.3V
– 5.0V
• Level converters between target section and EDBG section
• 32.768kHz crystal mounted
• 16MHz crystal footprint (not mounted)
• 2 CAN transceivers
• 1 LIN transceiver
– Wake-up button
– Master node pull-up enable
– Alternate LIN power jumper
• DAC output connector
• Analog voltage reference connector with filtered power supply
– SDADC VREF
– ADC/DAC VREF
• Supported with application examples in Atmel Software Framework
1.2

Kit Overview

The SAMC21N Xplained Pro evaluation kit is a hardware platform to evaluate the ATSAMC21N18A.
The kit offers a set of features that enables the ATSAMC21N18A user to get started with the SAM C
peripherals right away and to get an understanding of how to integrate the device in their own design.
©
