Table 3-1. EDBG LED Control
Operation Mode
Normal operation
Bootloader mode (idle)
Bootloader mode (firmware
upgrade)
For further documentation on the EDBG, see the
3.2

Hardware Identification System

All Xplained Pro compatible extension boards have an ATSHA204A CryptoAuthentication chip mounted.
This chip contains information that identifies the extension with its name and some extra data. When an
Xplained Pro extension is connected to an Xplained Pro MCU board the information is read and sent to
Atmel Studio. The Atmel Kits extension, installed with Atmel Studio, will give relevant information, code
examples, and links to relevant documents. The table below shows the data fields stored in the ID chip
with example content.
Table 3-2. Xplained Pro ID Chip Content
Data field
Manufacturer
Product Name
Product Revision
Product Serial Number
Minimum Voltage [mV]
Maximum Voltage [mV]
Maximum Current [mA]
3.3

Power Sources

The SAMC21N Xplained Pro kit can be powered by several power sources as listed in the table below.
Table 3-3. Power Sources for SAMC21N Xplained Pro
Power Input
External power
©
2017 Microchip Technology Inc.
Power LED
Power LED is lit when power is
applied to the board.
The power LED and the status LED blinks simultaneously.
The power LED and the status LED blinks in an alternating pattern.
EDBG User
Data type
ASCII string
ASCII string
ASCII string
ASCII string
uint16_t
uint16_t
uint16_t
Voltage Requirements
5V ±2% (±100mV) for
USB host operation.
4.3V to 5.5V if USB host
operation is not
required.
User Guide
SAMC21N Xplained Pro
Status LED
Activity indicator, LED flashes
when any communication
happens to the EDBG.
Guide.
Example content
Atmel'\0'
Segment LCD1 Xplained Pro'\0'
02'\0'
1774020200000010'\0'
3000
3600
30
Current Requirements
Recommended
minimum is 1A to be
able to provide enough
current for connected
USB devices and the
board itself.
Recommended
Connector Marking
PWR
DS70005318A-page 9
