Mechanical dimensions, motor mounting

FCD 303–315 340–480 Volt

Mechanical dimensions, stand alone mounting

The drawings below give the mechanical dimen-
sions. All dimensions are in mm.
FCD 303-315 380-480 Volt
MG.04.A1.02 - VLT is a registered Danfoss trade mark
®
VLT FCD Series
FCD 322–330 340-480 Volt
FCD 322–330 380–480 Volt
29
