Description of choice:
If Locked [1] is selected, data changes in the param-
eters cannot be made; however, it will still be
possible to make data changes via serial communi-
cation. Parameter 009-012 Display readout can be
changed via the control panel.
019 Operating mode at power-up, local opera-
019
tion
(POWER UP ACTION)
Value:
Auto restart, use saved reference
(AUTO RESTART)
Forced stop, use saved reference
(LOCAL=STOP)
Forced stop, set ref. to 0
(LOCAL=STOP , REF=0)
Function:
Setting of the required operating mode when the
mains voltage is engaged. This function can only be
active if Local operation [1] has been selected in pa-
rameter 002 Local/remote operation.
Description of choice:
Auto restart, use saved ref. [0] is selected if the fre-
quency converter is to start using the local reference
(set in parameter 003 Local reference) and the start/
stop state given via the control keys immediately
prior to the mains voltage being cut out.
Forced stop, use saved ref. [1] is selected if the fre-
quency converter is to remain stopped when the
mains voltage is engaged, until the [START]-key is
activated. After a start command the motor speed is
ramped up to the saved reference in parameter 003
Local reference.
Forced stop, set ref. to 0 [2] is selected if the fre-
quency converter is to remain stopped when the
mains voltage is cut back in. Parameter 003 Local
reference is to be zeroed.
= factory setting. () = display text [] = value for use in communication via serial communication port
54
®
VLT FCD Series
NB!:
In remote operation (parameter 002 Local/
remote operation) the start/stop state at the
time of mains connection will depend on the external
control signals. If Pulse start [8] is selected in pa-
rameter 302 Digital input, the motor will remain
stopped after mains connection.
024 Userdefined Quick Menu
024
(USER QUICKMENU)
Value:
Not active (DISABLE)
Active (ENABLE)
[0]
Function:
[1]
In this parameter you can opt out of the standard
setup of the Quick menu key on the control panel
[2]
and the LCP2 control panel.
Using this function, in parameter 025 Quick Menu
setup the user can select up to 20 parameters for
the Quick Menu key.
Description of choice:
If not active [0] is selected, the standard setup of the
Quick Menu key is active.
If Active [1] is selected, the user-defined Quick Menu
is active.
025 Quick Menu setup
025
(QUICK MENU SETUP)
Value:
[Index 1 - 20] Value: 0 - 999
Function:
In this parameter you define which parameters are
required in the Quick Menu when parameter 024
User-defined Quick Menu is set to Active [1]. ´
Up to 20 parameters can be selected for the user-
defined Quick Menu.
NB!:
Please note that this parameter can only be
set using an LCP2 control panel. See Order
form.
