Description of choice:
Set the required pulse reference or pulse feedback
to be connected to terminal 33.
328 Pulse Max. 29
328
(PULSE MAX 29)
Value:
1000 - 67600 Hz
Function:
This parameter is used for setting the signal value
that corresponds to the maximum value set in pa-
rameter 205 Maximum reference, Ref
maximum feedback value set in parameter 415 Max-
imum feedback, FB .
MAX
Description of choice:
Set the required pulse reference or pulse feedback
to be connected to terminal 29.
341 Digital output terminal 46
341
(DO 46 FUNCTION)
Value:
Drive ready (UNIT READ Y)
See the selection made in parameter 323 Relay
output.
Function:
The digital output can be used for giving the present
status or warning. The digital output (terminal 46)
gives a 24 V DC signal when a given condition is ful-
filled.
Description of choice:
Pulse output is to be selected if a pulse sequence is
required that corresponds to the reference value.
Pulse output can only be selected in parameter 341
Digital output. Pulse Output cannot be selected if
Pulse Reference or Pulse Feedback is selected in
parameter 305.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.A1.02 - VLT is a registered Danfoss trade mark
VLT
See parameter 323 Relay output for the other de-
scriptions.
342 Terminal 46, max. pulse scaling
342
Value:
150 - 10000 Hz
5000 Hz
Function:
This parameter is used for setting the pulse output
signal's maximum frequency.
or to the
MAX Description of choice:
Set the required frequency.
343 Precise stop function
343
Value:
Normal ramp stop (NORMAL)
Counter stop with reset
(COUNT STOP NO RESET)
Counter stop without reset
(COUNT STOP NO RESET)
[1]
Speed-compensated stop (SPD CMP STOP)
Speed-compensated counter stop with reset
(SPD CMP CSTOP W. RES)
Speed-compensated counter stop without reset
(SPD CMP CSTOP NO RES)
Function:
In this parameter you select which stop function is
performed in response to a stop command. All six
data selections contain a precise stop routine, thus
ensuring a high level of repeat accuracy.
The selections are a combination of the functions
described below.
Description of choice:
Normal ramp stop [0] is selected to achieve high
repetitive precision at the stopping point.
Counter stop. Once it has received a pulse start sig-
nal the frequency converter runs until the number of
pulses programmed by the user have been received
at input terminal 33. In this way an internal stop
signal will activate the normal ramp down time (pa-
rameter 208).
®
FCD Series
(DO 46 MAX. PULS)
(PRECISE STOP)
NB!:
Pulse start [8] may not be
used together with the precise stop function.
5000 Hz
[0]
[1]
[2]
[3]
[4]
[5]
81
