Display mode
VAR 1.1 VAR 1.2 VAR 1.3
VAR 2
STATUS
In normal operation, up to 4 different display data
items can optionally be shown continuously: 1,1,
1,2, 1,3 and 2. The present operation status or
alarms and warnings that have been generated are
displayed in line 2 in the form of a number.
In the event of alarms this is displayed in lines 3 and
4 with explanatory text.
A warning will appear flashing in line 2 with explana-
tory text in line 1. The active Setup will also appear
on the display.
The arrow indicates the selected direction of rota-
tion. Here the frequency converter shows that it has
an active reversing signal. The body of the arrow will
disappear if a stop command is given, or if the out-
put frequency drops below 0.1 Hz.
The bottom line displays the frequency transformer's
status. The scrollbar shows which operating values
can be displayed in lines 1 and 2 in Display mode.
Changes are made using the [+ / -] keys.
MG.04.A1.02 - VLT is a registered Danfoss trade mark
VLT
Operating data
Resulting reference
Resulting reference
Feedback
SETUP
Output frequency
1
Output frequency x scaling
Motor current
Torque
Power
Power
Motor voltage
DC link voltage
Thermal load motor
Thermal load
Hours run
Digital input
Pulse reference
External reference
Status word
Heatsink temperature
Alarm word
Control word
Warning word
Extended status word
Analogue input 53
Analogue input 60
Three operating data items can be shown in the first
display line, and one operating variable can be
shown in the second display line. Is programmed via
parameters 009, 010, 011 and 012 Display readout.
®
FCD Series
Unit
[%]
[unit]
[unit]
[Hz]
[-]
[A]
[%]
[kW]
[HP]
[V]
[V]
[%]
[%]
[hours]
[binary]
[Hz]
[%]
[hex]

[ C]
[hex]
[hex]
[hex]
[hex]
[V]
[mA]
