Technical data, mains supply 3 x 380 - 480 V

According to international stan-
dards
Output current
(3 x 380-480V)
Output power (400
V)
Typical shaft output
Typical shaft output
Max. cable cross
section, motor
Input current
(3 x 380-480 V)
Max. cable cross
section, power
Max. pre-fuses
3)
Efficiency
Power loss at max.
load
Weight
Enclosure
1. American Wire Gauge. Max. cable cross sec-
tion is the largest cable cross section that can be
attached to the terminals. Always observe national
and local regulations.
2. Type gG pre-fuses must be used. If you want to
maintain UL/cUL you must use pre-fuses of the
type Bussmann KTS-R 500 V or Ferraz Shawmut,
type ATMR (max. 30A). The fuses must be placed
for protection in a circuit that is capable of
supplying a maximum of 100,000 amps RMS (sym-
metrical), 500 V maximum.
3. Measured using a 10 m screened/armoured mo-
tor cable with a rated load and rated frequency.
134
VLT
Type 303 305
I [A] 1.4 1.8
INV.
I (60s) [A] 2.2 2.9
MAX
S [KVA] 1.0 1.2
INV.
P [kW] 0.37 0.55
M,N
P [HP] 0.50 0.75
M,N
2 1)
[mm /AWG] 4/10
I [A] 1.2 1.6
L,N
I (60s)[A] 1.9 2.6
L,MAX
2 1)
[mm /AWG] 4/10 4/10
2)
[IEC]/UL [A] 25/25 25/25
[%] 96
[W] 22 29
[kg] 5.8 5.8
type IP 66 / NEMA 4x (indoor)
®
FCD Series
307 311 315
2.2 3.0 3.7
3.5 4.8 5.9
1.5 2.0 2.6
0.75 1.1 1.5
1.0 1.5 2.0
4/10 4/10 4/10
1.9 2.6 3.2
3.0 4.2 5.1
4/10 4/10 4/10
25/25 25/25 25/25
40 59 80
5.8 5.8 5.8
MG.04.A1.02 - VLT is a registered Danfoss trade mark
322 330
5.2 7.0
8.3 11.2
3.6 4.8
2.2 3.0
3.0 4.0
4/10 4/10
4.7 6.1
7.5 9.8
4/10 4/10
25/25 25/25
117 160
7.0 7.0
