Select Special motor mode [8], if a special U/f set-
ting is needed that is to be adapted to the present
motor. The break points are set in parameters 423-
428 Voltage/frequency.
NB!:
Please note that if a value set in the name-
plate parameters 102-106 is changed, there
will be an automatic change of parameter 108 Stator
resistance and 109 Stator reactance.
102 Motor power P
102
M,N
(MOTOR POWER)
Value:
0.18 - 4 kW
Function:
Here you must set a power value [kW] P
sponding to the motor's rated power. The factory
sets a rated power value [kW] P
the type of unit.
Description of choice:
Set a value that matches the nameplate data on the
motor. Settings between one size below (for FCD
303 two sizes below) and one size over the factory
setting are possible.
103 Motor voltage U
103
M,N
(MOTOR VOLTAGE)
Value:
50 - 999 V
Function:
This is where to set the rated motor voltage U
1
either star Y or delta .
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.A1.02 - VLT is a registered Danfoss trade mark
Select a value that corresponds to the nameplate
data on the motor, regardless of the frequency con-
verter's mains voltage.
24-1000 Hz
This is where to select the rated motor frequency
f
Select a value that corresponds to the nameplate
data on the motor.
0,01 - I
The nominal, rated current of the motor I
part of the frequency converter calculation of fea-
Depends on unit
tures such as torque and motor thermal protection.
, corre-
M,N
Set a value that corresponds to the nameplate data
on the motor. Set the motor current I
, that depends on
M,N
account whether the motor is star-connected Y or
delta-connected
100 - f
This is where to set the value that corresponds to
the rated motor speed n
400 V
the nameplate data.
for
M,N
Select a value that corresponds to the nameplate
data on the motor.
®
VLT FCD Series
Description of choice:
104 Motor frequency f
104
M,N
(MOTOR FREQUENCY)
Value:
Function:
.
M,N
Description of choice:
105 Motor current I
105
M,N
(MOTOR CURRENT)
Value:
Depends on choice of motor
MAX
Function:
Description of choice:
1
.
106 Rated motor speed
106
(MOTOR NOM. SPEED)
Value:
x 60 (max. 60000 rpm)
M,N
Depends on parameter 102 Motor power, P
Function:
M,N
Description of choice:
50 Hz
forms
M,N
taking into
M,N
M,N
that can be seen from
