Warnings/alarm messages

A warning or an alarm will appear in the LEDs on
the LCP2. A warning will be shown until the fault
has been corrected, while an alarm will continue to
flash until the [STOP/RESET] key is activated.
The table shows the various warnings and alarms
shown in the LCP2, and whether the fault locks the
frequency converter. After a Trip locked (alarm and
warning LEDs flash at the same time), the mains
supply is cut off and the fault is corrected. The
mains supply is reconnected and the frequency con-
verter is reset. The frequency converter is now
ready. A Trip can be reset manually in three ways:
1. Via the operating key [STOP/RESET].
2. Via a digital input.
No. Description
2 Live zero error (LIVE ZERO ERROR)
4 Mains phase loss (MAINS PHASE LOSS)
5 Voltage warning high (DC LINK VOLTAGE HIGH)
6 Voltage warning low (DC LINK VOLTAGE LOW)
7 Overvoltage (DC LINK OVERVOL T)
8 Undervoltage (DC LINK UNDERVOL T)
9 Inverter overload (INVERTER TIME)
10 Motor overloaded ( MOTOR, TIME)
11 Motor thermistor (MOTOR THERMISTOR)
12 Current limit (CURRENT LIMIT)
13 Overcurrent (OVERCURRENT)
14 Earth fault (EARTH FAULT)
15 Switch mode fault (SWITCH MODE FAULT)
16 Short-circuit (CURR. SHORT CIRCUIT)
17 Serial communication timeout (STD BUS TIMEOUT)
18 HPFB bus timeout (HPFB TIMEOUT)
33 Out of frequency range (OUT FREQ RNG/ROT LIM)
34 HPFB communication fault (PROFIBUS OPT. FAULT)
35 Inrush fault (INRUSH FAULT)
36 Overtemperature (OVERTEMPERA TURE)
37-45 Internal fault (INTERNAL FAULT)
50 AMT not possible
51 AMT fault re. nameplate data (AMT TYPE.DA TA FAULT)
54 AMT wrong motor (AMT WRONG MOTOR)
55 AMT timeout (AMT TIMEOUT)
56 AMT warning during AMT (AMT WARN. DURING AMT)
99 Locked (LOCKED)
MG.04.A1.02 - VLT is a registered Danfoss trade mark
®
VLT FCD Series
3. Via serial communication.
It is also possible to choose an automatic reset in
parameter 405 Reset function. When a cross ap-
pears in both warning and alarm, this can mean that
a warning comes before an alarm. It can also mean
that it is possible for the user to programme whether
a warning or an alarm will appear for a given fault.
For example, this is possible in parameter 128 Motor
thermal protection. After a trip the motor will coast,
and alarm and warning will blink on the frequency
converter, but if the fault disappears only the alarm
will blink. After a reset the frequency converter will
be ready to start operation again.
Warning
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Alarm Trip
locked
X X
X X
X X
X X
X
X
X
X
X X
X X
X X
X X
X
X
X
X X
X
X X
X
X
X
X
X
