8-3 CALCulate Subsystem
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:LOWer:SHIFt
<numeric_value> {DB}
Title: Lower Limit Shift
Description: Move the lower limit up or down by a relative amplitude. This command changes the
value of :CALCulate<n>:LIMit<k>:LOWer[:DATA].
Issuing this command multiple times will change the limits each time. For example,
sending
CALC:LIM1:LOW:SHIFT 1 dB CALC:LIM1:LOW:SHIFT 1 dB CALC:LIM1:LOW:SHIFT
1 dB CALC:LIM1:LOW:SHIFT 1 dB CALC:LIM1:LOW:SHIFT 1 dB
will shift the lower limit by 5 dB.
If a limit of the specified number does not already exist, a default limit will be created
first (having empty data, with state set to ON).
Parameter(s): <numeric_value> {DB}
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:LOWer:STATe <0|1|ON|OFF>
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:LOWer:STATe?
Title: Lower Limit State
Description: Turns ON or OFF the lower limit.
If a limit of the specified number does not already exist, a default limit will be created
first (having empty data, with state set to ON).
Parameter(s): <0|1|ON|OFF>

:CALCulate:LIMit{[1]|2|3|4|5|6|7|8|9|10}:LOWer[:TRACe]:POINts?

Title: Lower Limit Points
Description: This command queries the upper limit trace points (Y-axis values) for the specified limit.
This differs from the limit data in that a value is returned for each point in the trace to
indicate the values that are being used to evaluate limit pass/fail status. The numeric
suffix on LIMit specifies which limit number to query or set data. If the suffix is omitted,
the command will refer to limit 1.If a limit of the specified number does not exist, an
empty list will be returned.
Parameter(s): none
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:NAME <string>
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:NAME?
Title: Limit Name
Description: Associates a user-defined name with each limit. The set version of this command takes a
single parameter that is a string containing the desired limit name. The query version
returns the name that is set.
If a limit of the specified number does not already exist, a default limit will be created
first (having empty data, with state set to ON).
Parameter(s): <string>
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:STATe <0|1|ON|OFF>
:CALCulate{[1]}:LIMit{[1]|2|3|4|5|6|7|8|9|10}:STATe?
Title: Limit State
Description: Turns the limit check for a specific limit ON or OFF.
8-10 PN: 10580-00427 Rev. C
SCPI SPA Commands
MS2760A UG
