1-5 Initial Inspection

1-5 Initial Inspection
Inspect the shipping container for damage. If the shipping container is damaged, retain it until the contents of
the shipment have been checked and the instrument has been checked for mechanical and electrical operation.
The following items are typically included with every shipment, but should be verified with the packing list:
• MS2760A Spectrum Analyzer
• 2000-1859-R 1.0 m USB A to C Port Cable
• 2000-1605-R BNC(m) to MCX(m) Cable (quantity 2)
• Certificate of Calibration
• 11410-00976 Getting Started Flier
If the shipment is incomplete or if the spectrum analyzer is damaged mechanically or electrically, notify your
local sales representative or Anritsu Customer Service. If the shipping container is damaged or shows signs of
stress, notify the carrier as well as Anritsu. Keep the shipping materials for the carrier's inspection.
1-6

Spectrum Master Identification

All Anritsu spectrum analyzers are assigned a unique seven digit serial number, such as "0701016". The serial
number is printed on a label that is affixed to the unit. When ordering parts or corresponding with Anritsu
Customer Service, please use the correct serial number with reference to the specific instrument's model
number.
1-7

Preparation for Storage/Shipment

Preparing the spectrum analyzer for storage consists of cleaning the unit, packing the inside with
moisture-absorbing desiccant crystals, and storing the unit in the recommended temperature environment.
Please refer to the data sheet for storage temperature recommendations.
To provide maximum protection against damage in transit, the spectrum analyzer should be repackaged in the
original shipping container. If this container is no longer available and the unit is being returned to Anritsu for
repair, please advise Anritsu Customer Service and use the following process to package the Spectrum Master
Ultraportable Spectrum Analyzer for shipment:
Note Disconnect any USB and Trigger cables before packaging the analyzer.
• Use a Suitable Container: Obtain a corrugated cardboard carton. This carton should have inside
dimensions of no less than 15 cm larger than the unit dimensions to allow for cushioning.
• Protect the Instrument: Surround the unit with polyethylene sheeting to protect the finish.
• Cushion the Instrument: Cushion the instrument on all sides by tightly packing urethane foam between
the carton and the unit. Provide at least three inches of dunnage on all sides.
• Seal the Container: Seal the carton by using either shipping tape or an industrial stapler.
• Address the Container: If the instrument is being returned to Anritsu for service, mark the address of
the appropriate Anritsu service center and your return address on the carton in one or more prominent
locations.
1-8

Contacting Anritsu

To contact Anritsu, please visit:
From here, you can select the latest sales, service and support contact information in your country or region,
provide online feedback, complete a "Talk to Anritsu" form to get your questions answered, or obtain other
services offered by Anritsu.
1-2
http://www.anritsu.com/contact-us
PN: 10580-00427 Rev. C
General Information
MS2760A UG
