8-10 MMEMory Subsystem

:MEASure:CHPower:CHPower?

Title: Measure Channel Power
Description: Sets the active measurement to channel power, sets the default measurement
parameters, triggers a new measurement and returns channel power as the result. To
measure both channel power and channel power density use MEASure:CHPower? It is a
combination of the commands :CONFigure:CHPower; :READ:CHPower? For a
description of the default channel power measurement parameters see
:CONFigure:CHPower. To make a channel power measurement with settings other than
the default values send: :CONFigure:CHPower Commands to set desired settings
:READ:CHPower?
Parameter(s): none

:MEASure:CHPower:DENSity?

Title: Measure Channel Power Density
Description: Sets the active measurement to channel power, sets the default measurement
parameters, triggers a new measurement and returns channel power density as the
result. To measure both channel power and channel power density use
MEASure:CHPower? It is a combination of the commands :CONFigure:CHPower;
:READ:CHPower? For a description of the default channel power measurement
parameters see :CONFigure:CHPower. To make a channel power measurement with
settings other than the default values send: :CONFigure:CHPower Commands to set
desired settings :READ:CHPower?
Parameter(s): none
8-10 MMEMory Subsystem
The commands in the Mass MEMory subsystem contain functions that provide access to the instrument setup
and data storage. The commands in the Mass MEMory subsystem contain functions that provide access to the
instrument setup and data storage.
:MMEMory:LOAD:LIMit <string>,<string>,<string>
Title: Load Limit From File
Description: This command loads limit data from the specified limit file. The file location is resolved
using the MSUS and file path parameters. Parameters: 1. Label: Used to specify which
limit to load. Currently, the label only supports loading all limits. Send an empty string
or "ALL" to load all limits. 2. File path: The file path (including file name) relative to the
MSUS root directory. File path is case sensitive. File extension is optional. 3. MSUS:
Device to load the file from. See MMEMory:MSUSs? for information on obtaining the list of
available devices. MSUS parameter is case sensitive. The model of the device that the
limit was saved in must match the model of the device to load in; otherwise, the load will
be rejected.
Parameter(s): <string>,<string>,<string>
:MMEMory:STOEvent:CLEarall
Title: Clear All Save On Event
Description: Turns off all save on event types that are active.
Parameter(s): none
8-26 PN: 10580-00427 Rev. C
SCPI SPA Commands
MS2760A UG
