ITW Dynatec DYNAMINI Operation And Service Manual page 85

Page 10-20 Component Illustrations & BOM's
Revised 11/02
4
7
Bill of Materials for 0.55cc/ Rev. Dual Gear Pump Assembly # 109909
Item No. Part Number
1
018X031
2
078F017
3
078I001
4
069X061
5
069X064
6
101692
7
101626
8
109906
9
100865
10
109905
11
N00198
12
109907
13
012D083
14
012D082
15
069X160
16
001U002
2
1
13
8
15
Description
Ball bearing, 1/8 Dia.
Snap ring, 1/2"
Key Woodruf, #404
Shaft Seal
O-ring, -041
M4-0.7 x 35mm SHC Screw
M5-0.8 x 12mm SHC Screw
Plate Front, .55cc/ Rev.
Rear Bearing Plate .55cc Rev.
Plate, Middle Gear, 0.55/ Rev.
O-ring, -113
Gear .55cc Rev
Drive Shaft 1.5 cc Dual
Driven Shaft, 1.5 cc Dual
Shaft Seal Retainer
Dow Corning 112 Lubricant (Not Shown)
DYNAMINI ASU Manual #20-25
11
12
14
3
5
c. 2004
12
5
10
Qty.
6
4
1
1
2
2
4
1
1
1
2
4
1
1
1
5
6
9
