ITW Dynatec DYNAMINI Operation And Service Manual page 79

Page 10-14 Component Illustrations & BOM's
Revised 12/97 Rev. C Eng: JW
Bill of Materials for 4.50 cc / Rev. , Single Gear Pump Assembly # 100862
Item No. Part Number
012D072
1
078I001
2
101626
3
069X160
4
069X061
5
018X041
6
100868
7
012D073
8
018X031
9
012C018
10
069X064
11
078F017
12
018X041
13
100865
14
100908
15
104158
16
104073
17
Description
Drive Shaft
Key, Woodruff
M5 x 12 SHC Screw
Seal Retainer & Bearing Housing
Lip Seal
Bearing Sleeve
Front Plate Assembly
Driven Gear Shaft
Ball, 1/8" Diameter
Drive Gear, 4.5 cc/rev
Pump Seal
Shaft Retaining Ring
Bearing Sleeve, Rear Plate
Rear Plate Assembly
M4 x 25 SHC Screw
M10 Flange Nut
M10-1.5 x 105 All Thread
c. 2004
DYNAMINI ASU Manual #20-25
Qty.
1
1
4
1
1
2
1
1
4
2
2
4
2
1
2
4
4
