Page 5-8
Revised 1/05
Service Functions,
To Change Access Code (De-activate Keypad Locking)
To change the Access Code, press the Service icon six
x 6
times.
You will see "C--1" to indicate you are in Access Code
programming mode.
Press the Tank icon to see the programmed Access
Code. For example, "999".
To change the Access Code, scroll up or down to the desired
numeric value.
or
"-- -- --" = no Access Code (Access code is de-activated),
"-- -- --" = no Keypad Locking
1 - 999 = possible Access Code values
When programming is complete, wait a few seconds and the controller will return to
the ASU's actual temperature.
cont.
