Settings for a Typical Operation

Note: The values given here are approximate settings for a typical packaging operation. The values
you choose will be based on the type of equipment and adhesive you are using and the nature of
your particular operation.
If Application Temperature is 163°C (325°F):
·
Hose and head temperature: 177°C (350°F).
·
Hopper setpoint temperature: 150°C (300°F).
·
ASU operating range: 135°C to 177°C (275°F to 350°F).
·
Mechanical thermostat (for the hopper) over-temperature: 232°C (450°F)
System Values That Are Permanently Programmed
·
Minimum setpoint value: 40°C (100°F).
·
Maximum setpoint value: 218°C (425°F).
System Values as Programmed by the Factory
ITW Dynatec can set the controller's system values to customer's specs, if provided.
If customer's specs are not provided, the following values will be entered into the Dynamini tem-
perture controller at the factory. They may be changed by reprogramming through the keypad.
(These are not the "default" settings, see following section).
·
Temperature scale: displayed in degrees Farenheit.
·
Applicator (head) and hose setpoints: 177°C (350°F).
·
Hopper setpoint: 150°C (300°F).
·
All zones are switched off, except for the hopper.
