Electrical Panel Assembly - ITW Dynatec DYNAMINI Operation And Service Manual

Page 10-2 Component Illustrations & BOM's
Revised 12/04
Bill of Materials for DYNAMINI Electrical Panel Assembly
Part Number
Item No.
1 102241
2 102240
3 102239
4 102246
5 105032
6 111668
7 111660
111678
8 108297
9 110745
10 108745
11 105113
12 111677
13 106157
14 111363
15 107391
16 108566
17 102767
18 05.11020.004
19 105164
20 105199
21 102245
Description
Front Cover End (Part of 111669 front Panel Assy)
Back Cover End
Base DYNAMINI
Panel Divider
Diode (120V models only)
Printed Circuit Board / Heat Sink Assembly
Receptacle And Wiring Harness (240V)
Receptacle And Wiring Harness (120V)
M8-10 x 20mm Hex Flange Screw
Ground Lug
Screw Ground spade
M4 X 8mm SHC Screw
Ground spade assm
Lock Washer, Int. Tooth
Control Panel (of 111669 front panel assy.)
Hex Nut
Fuse, PCB, 6.3 amp
Fuse 1 amp Slow
Fuse 2 amp Slow
Washer, #8
Elbow, 90° Conduit Fitting
Heat Shield
c. 2004
DYNAMINI ASU Manual #20-25
