Piston Pump & Air Motor Assembly #105072 (cont.)
Item Part Number
109970
27 * N00183
28 102243
29 *
N01703
30 * N01702
31 100344
32 * N01614
33 * N00190
34 * N01618
35 * L16543
36 L16534
37 N06918
38 N00723
39 * 069X270
40
101156
41 * 107011
42 N07121
43 * 107010
44 N00187
45 N07677
46 100380
47 N06430
48 105113
49 101888
50 N01067
Note:
39
43
29
30
29
33
30
31
30
29
17
49
47
45
Description
Air Motor Assembly
O-ring, -016
Piston Pump Mounting Block
Plug Fitting
O-ring , -904
Piston Pump Body
O-ring, -910
O-ring, #-024
Plug Fitting
Pump Shaft
Piston, Pump Shaft
Bellevue Washer, 1/4
1/4-20 x .50 HHC Screw
O-ring, -025
M6 x 20 SHC Screw (Note: torque to 90 in/lbs (10nm))
Outlet Check Valve, Service Assembly (available as an assembly only)
O-ring, -111
Inlet Check Valve Assembly (available as an assembly only)
O-ring, -020
Fittings For Coalescing Air Filter
TFE Tubing, .250 Diameter
Filter Assembly
Brass Male Connect Fitting
M4 x 8 SHC Screw
Air Block
Brass Nipple
*These items are included in Piston Pump Rebuild Kit 109969 (replaces 105330)
