Pressure Gauge Kit; Filter Option; Pump Options & Accessories - ITW Dynatec DYNAMINI Operation And Service Manual

ITW Dynatec c. 2004
DYNAMINI ASU Manual #20-25
Pressure Gauge Kit: PN 101175
An optional analog pressure gauge can be mounted on the outlet filter manifold. Reading the adhe-
sive pressure at the manifold, rather than in-line on a hose, allows for more precise monitoring of
system pressure. It is also useful for troubleshooting and maintenance.
The gauge is installed at one of the adhesive ports on the manifold (see illustration on page 3-5).
There is no "dedicated" port for the gauge, any one of the three ports on the manifold may be used.
Fittings, o-rings and a plug are included in the kit.

Filter Option:

40 Mesh Outlet Filter: PN 101246
Some situations do not call for a fine mesh outlet filter. A "clean" adhesive or one with a long pot
life are examples. Systems utilizing lower temperatures or systems running in a clean environment
can also utilize a 40 mesh filter. Standard equipment on Dynamini is a 100 mesh filter (PN 101247).
Pump Options and Accessories:
12:1 Piston Pump: PN 105072 (120v) or 105073 (240v)
The ASU is available with a constant-pressure, air-operated piston pump. It provides smooth output
pressure and insures a high pressure adhesive output from a low pressure, compressed air input. A
piston pump is superior for intermittent applications which require no volumetric control.
Piston Pump Repair Kit: PN 105328
The Piston Pump Repair Kit contains the following items needed to rebuild the 12:1 piston pump:
PN Description
L16569 Bearing & Shaft Seal Kit
108772 O-ring, Adapter Plate
108700 Lube, Seal, 1/4 oz.
N01703 Fitting
N01618 Fitting
N07121 Ring, Seal, 111
Piston Pump Rebuild Kit: PN 109969
This kit contains a PN 105328 Pump Repair Kit, a PN 109968 Pump & Airmotor Seals Kit, a
L16534 Pump Shaft, a L21189 Inlet Check Valve Assembly and a L21188 Outlet Check Valve As-
sembly.
Piston Pump Bearing and Shaft Seal Kit: PN L16569
This kit contains all items needed to replace the piston pump's shaft seal and bearing, including
seals, o-ring, pump shaft bearing and retaining ring. A seal pedestal and o-ring lubricant are also
included.
Chapter 9
AVAILABLE OPTIONS & ACCESSORIES
Qty.
1
1
1
3
1
1
PN Description
N00183 O-ring, 016
N01614 O-ring, 910
N00190 O-ring, 024
N01702 O-ring, 904
N00187 O-ring, 020
069X270 O-ring, 025
Page 9-1
Revised 1/05
Qty.
1
1
1
3
1
1
