Page 2 -4
Revised 1/05
A
DIMENSION
MODEL 05 (mm)
MODEL 05 (inches)
MODEL 10 (mm)
MODEL 10 (inches)
* All Mounting holes are 10mm diameter.
B
C
H
A
B
C
289
527
540
11.38
20.75
21.25
289
527
540
11.38
20.75
21.25
DYNAMINI Installation Dimensions
DYNAMINI ASU Manual #20 -25
A
D
D
E
F
238
451
635
9.37
17.75
25.0
238
654
838
9.37
25.75
33.0
ITW Dynatec c. 2004
F
E
G
G
H
mounting holes*
249
381
9.8
15.0
249
381
9.8
15.0
