ITW Dynatec DYNAMINI Operation And Service Manual page 77

Page 10-12 Component Illustrations & BOM's
Revised 1/98 Rev. C Eng: JW
Bill of Materials for 1.54 cc / Rev. , Single Gear Pump Assembly # 100860
Bill of Materials for 3.2 cc / Rev. , Single Gear Pump Assembly # 100861
Item No. Part Number
#100860 / #100861
1 012D079 / 012D077
2 078I001
3 101626
4 069X160
5 069X061
6 018X041
7 100866 / 100867
8 012D080 / 012D078
9 018X031
10 012C020 / 012C019
11 069X064
12 078F017
13 018X041
14 100865
15 100908
16 104158
17 104073
Description
Drive Shaft
Key, Woodruff
M5 x 12 SHC Screw
Seal Retainer & Bearing Housing
Lip Seal
Bearing Sleeve
Front Plate Assembly
Driven Gear Shaft
Ball, 1/8" Diameter ( See illustration for quantity)
Drive Gear,
Pump Seal
Shaft Retaining Ring
Bearing Sleeve, Rear Plate
Rear Plate Assembly
M4 x 25 SHC Screw
M10 Flange Nut
M10-1.5 x 105 All Thread
