DYNAMINI ASU Manual 20-25
Pressurized Air In
Air pressure gauge
Hose/ Head
Electrical Connections
120v 240v
Electrical #1
Electrical #1
Electrical #2 Electrical #2
Rear Cover: Hose and Head Electrical and Adhesive Connections
Air Pressure Regulator (clockwise increases)
1/4 NPT female
Coalescing filter
Air Control/ Filter Unit
Maintain adhesive level 13mm-100mm (1/2"-
4") from top of hopper.
Output Filter Manifold
Air Flow
Pre-filter
Adjustable Pressure
Relief Valve
Air Control/ Filter Unit
Pressure Gauge (optional)
Hose/ Head Adhesive Ports
Adhesive Port Connections
# 1
Adhesive Supply
Hose
Page 3-5
Revised 1/05
Gauge
# 2
