5. System setting and operation
How to setup the device
19. Program DVI1 output is the default main image of the system, it mainly
connects large screen sending card, current VSP 737 supports resolutions
as below:
800x600_60Hz, 1024x768_60Hz, 1280x768_60 Hz,
1280x1024_60 Hz, 1366x768_60 Hz, 1440x900_60_nr Hz,
1440x900_60 Hz, 1600x1200_60 Hz, 1600x1200_60_r Hz,
1920x1080_60 Hz
Note
Via pressing MENU OUTPUT OUTPUT
FORMAT to select needed output resolution.
Except for CONT part, sending card and power port, other ports are video
signal input ports.
DVI（DVI-I port）can connect PC VGA card's DVI output port, or via
DVI-to-HDMI wire to connect PC VGA card's HDMI output port or DVD's
HDMI output port;
VGA（DB15 port）can connect PC VGA card's VGA output port, or via
VGA-to-YPBPR wire to connect DVD's YPBPR HD component output;
CVBS （ BNC port ） can connect DVD's composite video output or
expression video recorder's composite video output via RCA-to-BNC wire;
USB（USB-A port）can connect USB device or mobile HDD with USB
memory function. Supportive picture formats ： JPGE, BMP, PNG ；
Supportive video formats：MP4, MPEG1, MPEG2, RMVB, MJPG. This port
can also be used to update image firmware.
25. AEC port：Plug in power, power range: AC 85-264V 50/60Hz
26. Power switch: Button lights on, device powers up;
