Identification
8
2.1.3
Nameplate for connections
See operating manual
Betriebsanleitung beachten
Observer manuel d'instruction
12345678912
Ser.No.:
1
Supply /
4
Versorgung /
Tension d'alimentation
26= FF +
27= FF -
5
Ex-works / ab-Werk / réglages usine
6
Device SW:
7
Communication:
8
Drivers:
9
Date: DD. MMM. YYYY
Fig. 3:
Nameplate specifications for Proline transmitter connections (example)
1
Serial number
2
Possible configuration of current output
3
Possible configuration of relay contacts
4
Terminal assignment, cable for power supply
Terminal no. 1:
– L1 for AC, L+ for DC
Terminal no. 2:
– N for AC, L- for DC
5
Signals present at inputs and outputs, possible configurations and terminal assignment
6
Version of device software currently installed (incl. language group)
7
Type of communication installed
8
Information on current communication software (Device Revision, Device Description)
9
Date of installation
10
Current updates to data specified in points 6 to 9
Proline Promag 53 FOUNDATION Fieldbus
A:
P:
NO:
NC:
L1/L+
N/L-
PE
FOUNDATION Fieldbus
Update 1
XX.XX.XX
(WEA)
FOUNDATION Fieldbus
ID XXXX (HEX)
319475-00XX
active
passive
normally open contact
normally closed contact
1
2
Update 2
Endress+Hauser
2
3
X
a0006396
