Proline Promag 53 FOUNDATION Fieldbus
Endress+Hauser
Device starting current
< 12 mA
Device error current (FDE)
0 mA
Device (lift off) min. voltage
9 V (H1 segment)
Permissible fieldbus supply voltage
9 to 32 V
Integrated reverse polarity protection
Yes
ITK version
5.01
Number of VCRs (total)
38
Number of link objects in VFD
40
Galvanic isolation
All circuits for inputs, outputs and power supply are galvanically isolated from each other.
Data transmission rate
31.25 kbit/s, voltage mode
Bus times
Min. idle time between two telegrams:
MIN_INTER_PDU_DELAY = 6 octet time (transfer time per octet)
Block information, execution times
Block
Resource Block
"Flow" Transducer Block
"Diagnosis" Transducer Block
"Display" Transducer Block
"Totalizer" Transducer Block
Analog Input function block 1
Analog Input function block 2
Analog Input function block 3
Analog Input function block 4
Analog Input function block 5
Discrete Output function block (DO)
Base index Execution time [ms]
400 –
1400 –
1600 –
1800 –
1900 –
500 18
550 18
600 18
650 18
700 18
850 18
Technical data
Functionality
Enhanced
Vendor specific
Vendor specific
Vendor specific
Vendor specific
Standard
Standard
Standard
Standard
Standard
Standard
