Technical data
106
Block
PID function block (PID)
Arithmetic function block (ARTH)
Input Selector function block (ISEL)
Signal Characterizer function block
(CHAR)
Integrator function block (INTG)
Output data
Transducer Blocks/Analog Input function blocks
Block
"Flow" Transducer Block
"Totalizer" Transducer Block
Input data
Discrete Output function block (channel 16)
Status change
Discrete state 0  Discrete state 1
Discrete state 0  Discrete state 2
Discrete state 0  Discrete state 3
Discrete state 0  Discrete state 4
Discrete state 0  Discrete state 5
Discrete state 0  Discrete state 6
Discrete state 0  Discrete state 7
Discrete state 0  Discrete state 8
Discrete state 0  Discrete state 9
Discrete state 0  Discrete state 10
Discrete state 0  Discrete state 27
Discrete state 0  Discrete state 28
VCRs
VCRs (total 48)
Permanent Entries
Client VCRs
Server VCRs
Source VCRs
Sink VCRs
Subscriber VCRs
Publisher VCRs
Proline Promag 53 FOUNDATION Fieldbus
Base index Execution time [ms]
900 25
1000 20
1050 20
1100 20
1150 18
Process variable
Calculated mass flow
Volume flow
Totalizer 1
Totalizer 2
Totalizer 3
Action
reserved
Positive zero return "ON"
Positive zero return "OFF"
reserved
reserved
reserved
Reset Totalizer 1, 2, 3
Reset Totalizer 1
Reset Totalizer 2
Reset Totalizer 3
Permanent Storage "OFF"
Permanent Storage "ON"
48
1
0
24
23
0
23
23
Functionality
Standard
Standard
Standard
Standard
Standard
Channel parameter
(AI Block)
1
2
7
8
9
