TPD/VPD Series HMI Device User Manual
1.4.8 VPD-130-H/130N-H/132-H/132N-H/133-H/1
33N-H
Models
CPU Module
CPU
Memory Expansion
Real Time Clock (RTC)
Buzzer
Rotary Switch (0 ~ 9)
Communication Interface
Ethernet
COM1
COM2
USB 1.1 Client
I/O Expansion
I/O Expansion Bus
MMI (Main Machine Interface)
LCD
Backlight Life
Brightness
LED Indicator
Touch Panel
Reset Button
Rubber Keypad
Electrical
Powered from Terminal Block
Powered from PoE
Power Consumption
Mechanical
Dimensions (W x L x H)
Installation
Ingress Protection
Environmental
Operating Temperature
Storage Temperature
Ambient Relative Humidity
Copyright © 2017 ICP DAS Co., Ltd. All Rights Reserved.
VPD-130-H VPD-130N-H
-
RS-232/RS-485 (including
Self-Tuner)
-
Yes, One of XV-boards
3.5" TFT (Resolution 240 x 320 x 16), defective pixels <= 3
Yes -
5 keys -
(Programmable)
-
DIN-Rail Mounting and Panel Mounting
VPD-132-H VPD-132N-H
32-bit RISC CPU
16 MB SDRAM /16 MB Flash
Yes
Yes
Yes
RS-485 (including Self-Tuner) and RS-232 (3-pin)
RS-485 (including Self-Tuner)
Firmware update only
20,000 hours
270 cd/m2
Yes -
Yes
Yes
5 keys -
(Programmable)
+12 ~ +48 V
DC
2 W
103 mm x 103 mm x 53 mm
Front Panel: IP65
-20 ~ +50°C
-30 ~ +80°C
10 ~ 90% RH, non-condensing
VPD-133-H VPD-133N-H
RJ-45 x 1, 10/100 Base-TX
Yes -
5 keys -
(Programmable)
IEEE 802.3af, Class1 (48 V)
