Configuring IP Addressing

Forwarding UDP Broadcast Packets and Protocols

User Datagram Protocol (UDP) is an IP host-to-host layer protocol. UDP provides a connectionless
session between two end systems and does not acknowledge received datagrams. Network hosts can use
UDP broadcasts to find address, configuration, and name information. If such a host is on a network
segment that does not include a server, UDP broadcasts might not be forwarded. However, you can
configure an interface on a router to forward certain broadcast classes to a helper address. You can use
more than one helper address per interface.
You can specify a UDP destination port to control which UDP services are forwarded. You can specify
multiple UDP protocols. You can also specify the Network Disk Protocol (NDP), which is used by older
diskless Sun workstations and the network security protocol SDNS.
By default, both UDP and NDP forwarding are enabled if a helper address has been defined for an
interface. The description for the ip forward-protocol interface configuration command in the Cisco
IOS IP Command Reference, Volume 1 of 3: Addressing and Services, Release 12.2 lists the ports that
are forwarded by default if you do not specify any UDP ports.
If you do not specify any UDP ports when you configure the forwarding of UDP broadcasts, you are
configuring the router to act as a BOOTP forwarding agent. BOOTP packets carry DHCP information.
Beginning in privileged EXEC mode, follow these steps to enable forwarding of UDP broadcast packets
on an interface and to specify the destination address:
Command
Step 1 configure terminal
Step 2 interface interface-id
Step 3 ip helper-address address
Step 4 exit
Step 5
ip forward-protocol {udp [port] | nd | sdns} Specify which protocols the router forwards when forwarding
Step 6 end
Step 7 show ip interface [interface-id]
or
show running-config
Step 8
copy running-config startup-config
Use the no ip helper-address interface configuration command to disable the forwarding of broadcast
packets to specific addresses. Use the no ip forward-protocol global configuration command to remove
a protocol or port.
Establishing an IP Broadcast Address
The IP broadcast address (and the default) is an address consisting of all ones (255.255.255.255).
However, the switch can be configured to generate any form of IP broadcast address.
Cisco Catalyst Blade Switch 3130 and 3032 for Dell Software Configuration Guide
38-16
Purpose
Enter global configuration mode.
Enter interface configuration mode, and specify the Layer 3 interface
to configure.
Enable forwarding and specify the destination address for forwarding
UDP broadcast packets, including BOOTP.
Return to global configuration mode.
broadcast packets.
Return to privileged EXEC mode.
Verify the configuration on the interface or all interfaces.
(Optional) Save your entries in the configuration file.
Chapter 38 Configuring IP Unicast Routing
OL-12247-04
