Chapter 36 Configuring QoS
Command
Step 10
end
Step 11 show mls qos aggregate-policer
[aggregate-policer-name]
Step 12 copy running-config startup-config
To remove the specified aggregate policer from a policy map, use the no police aggregate
aggregate-policer-name policy map configuration mode. To delete an aggregate policer and its
parameters, use the no mls qos aggregate-policer aggregate-policer-name global configuration
command.
This example shows how to create an aggregate policer and attach it to multiple classes within a policy
map. In the configuration, the IP ACLs permit traffic from network 10.1.0.0 and from host 11.3.1.1. For
traffic coming from network 10.1.0.0, the DSCP in the incoming packets is trusted. For traffic coming
from host 11.3.1.1, the DSCP in the packet is changed to 56. The traffic rate from the 10.1.0.0 network
and from host 11.3.1.1 is policed. If the traffic exceeds an average rate of 48000 b/s and a normal burst
size of 8000 bytes, its DSCP is marked down (based on the policed-DSCP map) and sent. The policy
map is attached to an ingress port.
Switch(config)# access-list 1 permit 10.1.0.0 0.0.255.255
Switch(config)# access-list 2 permit 11.3.1.1
Switch(config)# mls qos aggregate-police transmit1 48000 8000 exceed-action
policed-dscp-transmit
Switch(config)# class-map ipclass1
Switch(config-cmap)# match access-group 1
Switch(config-cmap)# exit
Switch(config)# class-map ipclass2
Switch(config-cmap)# match access-group 2
Switch(config-cmap)# exit
Switch(config)# policy-map aggflow1
Switch(config-pmap)# class ipclass1
Switch(config-pmap-c)# trust dscp
Switch(config-pmap-c)# police aggregate transmit1
Switch(config-pmap-c)# exit
Switch(config-pmap)# class ipclass2
Switch(config-pmap-c)# set dscp 56
Switch(config-pmap-c)# police aggregate transmit1
Switch(config-pmap-c)# exit
Switch(config-pmap)# exit
Switch(config)# interface gigabitethernet2/0/1
Switch(config-if)# service-policy input aggflow1
Switch(config-if)# exit

Configuring DSCP Maps

These sections contain this configuration information:
•
•
•
•
•
OL-12247-04
Configuring the CoS-to-DSCP Map, page 36-68
Configuring the IP-Precedence-to-DSCP Map, page 36-69
Configuring the Policed-DSCP Map, page 36-70
not appropriate)
Configuring the DSCP-to-CoS Map, page 36-71
Configuring the DSCP-to-DSCP-Mutation Map, page 36-72
map are not appropriate)
Cisco Catalyst Blade Switch 3130 and 3032 for Dell Software Configuration Guide
Purpose
Return to privileged EXEC mode.
Verify your entries.
(Optional) Save your entries in the configuration file.
(optional)
(optional, unless the null settings in the map are
(optional)
Configuring Standard QoS
(optional)
(optional, unless the null settings in the
36-67
