RED DSMC POWER OPERATION GUIDE

EPIC/SCARLET POWER OPERATIONS

This section describes the basic power operations for EPIC and SCARLET.
EPIC/SCARLET POWER INPUTS
Figure: SEARAY Connector (Top) and DC IN Connector (Bottom)
There are two (2) primary power inputs that provide power to the EPIC/SCARLET:
# POWER INPUT
1 SEARAY™ power connector Provides power to the BRAIN
2 DC IN connector
NOTE: Additionally, one (1) REDVOLT
short term power and support hot-swapping of other power sources.
C O PYR I G HT © 2 0 1 7 R ED.C O M , LLC
DESCRIPTION
Provides power to the BRAIN using a DSMC AC Power Adaptor or certain battery
modules, such as the Backpack Quickplate (Short)
®
battery may be used in conjunction with the DSMC Side Handle to provide
®
from attached EPIC/SCARLET modules
