RED DSMC POWER OPERATION GUIDE
REDVOLT XL MODULE
SPECIFICATION
Dimensions
Weight
Construction
Operating Temperature
Storage Temperature
Connectors
Firmware Requirement
QUICKPLATE MODULE
SPECIFICAITON
Dimensions
Weight
Construction
Operating Temperature
Storage Temperature
Connectors
Firmware Requirement
C O PYR I G HT © 2 0 1 7 R ED.C O M , LLC
DESCRIPTION
Height: 4.29" (109 mm)
Width: 4.41" (112 mm)
Depth: 1.52" (39 mm)
Approximately 0.94 lbs (425 g), Module only
Aluminum Alloy
0°C to 40°C (32°F to 104°F)
–20°C to 50°C (–4°F to 122°F)
CHARGE IN (6-pin 1B LEMO)
AUX POWER OUT (2-pin 0B LEMO)
DSMC firmware v5.1.29 or later
DESCRIPTION
Height: 4.29" (109 mm)
Width: 4.41" (112 mm)
Depth: 1.52" (39 mm)
Approximately 0.70 lbs (317 g), Module only
Aluminum Alloy
0°C to 40°C (32°F to 104°F)
–20°C to 50°C (–4°F to 122°F)
AUX 1 (2-pin 0B LEMO)
AUX 2 (2-pin 0B LEMO)
DSMC firmware v5.1.14 or later
