RED DSMC POWER OPERATION GUIDE

REDVOLT AND REDVOLT XL

Figure: REDVOLT XL (Left) and REDVOLT (Right)
REDVOLT and REDVOLT XL batteries are lightweight and rechargeable batteries designed to power the camera.
REDVOLT batteries can be mounted to DSMC
DSMC Side Handle for short term power.
NOTE: REDVOLT and REDVOLT XL batteries require a REDVOLT Travel Charger (REDVOLT only), REDVOLT Charger
(Quad), or REDVOLT XL Module (REDVOLT XL only) to recharge.
®
NOTE: A DSMC2 REDVOLT XL Module is required to use a REDVOLT XL battery with WEAPON
®
RED RAVEN , and RED EPIC-W
NOTE: A DSMC2 REDVOLT Expander is required to use a REDVOLT battery with WEAPON, SCARLET-W, RAVEN,
and EPIC-W cameras.
REDVOLT batteries are compatible with following DSMC power modules:
"DSMC Side Handle" on page 25
"Pro Battery Module (Dual)" on page 33
"Pro Battery Module (Quad)" on page 34
"REDVOLT XL Module" on page 36
"DSMC2 REDVOLT XL Module" on page 48
REDVOLT batteries should only be charged using the following approved RED chargers:
"REDVOLT Travel Charger" on page 67
"REDVOLT Charger (Quad)" on page 68
"RED BRICK Charger" on page 70
C O PYR I G HT © 2 0 1 7 R ED.C O M , LLC
®
power modules for extended mobile power, or inserted into the
®
cameras.
(REDVOLT XL only)
®
, SCARLET-W,
9 5 5 - 0 0 3 8 , R EV - AD | 6 1
