RED DSMC POWER OPERATION GUIDE
EPIC/SCARLET POWER LEDS
This section describes the LED functions for the camera.
LED
Power Status LED
(PWR)
Record Status LED
(REC)
Power Status LED (PWR)
and Record Status LED (REC)
EPIC/SCARLET POWER PRIORITY
When multiple power sources are connected to the EPIC/SCARLET, power consumption is prioritized in this
sequence:
1. DC IN (AC power adapter or external battery)
2. Rear battery module batteries (lowest state of charge first)
3. REDVOLT battery in an attached DSMC Side Handle
EPIC/SCARLET POWER CONSUMPTION
The EPIC/SCARLET draws approximately 60 W when recording in 5K resolution, at 24 FPS.
Under typical conditions batteries provide the following operating time:
REDVOLT: Powers the camera and accessories for approximately 30 minutes.
REDVOLT-V™: Powers the camera and accessories for approximately 35 minutes.
REDVOLT XL: Powers the camera and accessories for approximately 90 minutes.
RED BRICK: Powers the camera and accessories for approximately 120 minutes.
C O PYR I G HT © 2 0 1 7 R ED.C O M , LLC
COLOR/FLASHING
Off
Green
Amber flashing
Amber
Red flashing
Red
Off
Green
Amber
Red flashing (slow)
Red flashing (fast)
Red
Both green flashing
Both red flashing
DESCRIPTION
No power present
Power present; camera on
Power present; 5–10 min of battery time left
Power present; camera booting
Power present; < 5 min of battery time left
Power present; camera off
No media present
Ready to record
Finalizing
Recording; 25% media left
Recording; 5% media left
Recording
Firmware update in progress
Firmware update error
