14.2 Fuses and Fuse Code for UL

Bussmann Div Cooper (UK) Ltd
(200 kARMS Symmetrical A.I.C.)
SIZE
Fuse
CODE
15A FWC 16A10F
25A FWC 32A10F
35A FWP 40A14F
45A FWP 50A14F
60A FWP 80A22F
90A -
110A -
Caution: The Fuses must have I²t 20% less than thyristor's I²t.
Caution: High speed fuses are used only for the thyristor protection and can not be used to
protect the installation.
Caution: The warranty of thyristor is null if no proper fuses are used. See tab.
Warning: The user installation must be protected by electromagnetic circuit breaker or by
fuse isolator.
CD3200-1PH from 15A to 110A
Current I²T
(ARMS) (A²sec)
16 150
32 600
40 750
50 1800
80 6600
- -
- -
Ferraz Shawmut SA
(200 kARMS Symmetrical A.I.C.)
Fuse
Vac
CODE
660 Grb
600
10-16
660 Grb
600
10-32
CP URC
700
14x51/40
CP URC
700
14x51/50
CP URD
700
22x58/80
CP URQ
-
27x60/125
CP URQ
-
27x60/160
U L
C US
®
LISTED
45
User's Manual
Current I²T
(ARMS) (A²sec)
16 145
32 740
40 700
50 1500
80 3800
125 6970
160 15000
Qty
Vac
660 1
660 1
660 1
660 1
660 1
660 1
660 1
