Order Code - CD Automation CD3200 User Manual

CD Automation srl

5.2 Order Code

Model 1
CD3200
1 Max Current of CD3200
15A 35A
25A 45A
The Max Current must be equal or more than Load Current
2 Load Current
Specify this value to configure the unit in CD Automation
3 Load Voltage
Specify this value to configure the unit in CD Automation
4 Max Voltage of CD3200
480V
600V
The Max Voltage must be equal or more than Load Voltage
5 Auxiliary Voltage (Voltage supply for the Electronic boards)
90:130 From
170:265 From 170 to 265Vac; 10VA
230:345 From 230 to 345Vac; 10VA
300:530 From 300 to 530Vac; 10VA
510:690 From 510 to 690Vac; 10VA
6 Input
0÷10V 0÷10Vdc
4÷20mA 4÷20mA
POT Potentiometer 10KΩ
7 Firing Type
S+PA Soft Start + Phase Angle
PA Phase Angle
8 Feed Back
V Voltage
I Current
V2 Voltage square
VxI Power (VxI)
9 Option
NCL No current limit
CLP External current limit profiling (0÷10Vdc)
EN Opto isolated external enable
FBS Opto isolated Feed-back Selection
EF External fuses and fuse holders
NF No fuses
HB Heater Break Alarm
CD-KP External Keypad
110Fan Fan voltage supply 110VAC ± 15% (std 230VAC ± 15%) 50/60Hz
EP External Protection IP20 for size S7C and S8C
UL UL Certification
CD3200-1PH from 15A to 110A
2 3
60A
90A
90 to 130Vac; 10VA
4 5 6
110A
12
User's Manual
7 8 9
