12.5 Error and exception responses

If a message contains an altered character, if fails the CRC, or if the received message contains a syntax

error (for example the number of the byte or of the words is not correct), then the unit will ignore the

message.

If the received message is correct but contains a not valid value, the unit will send an answer of

exception (5 byte):

Address Unit

The byte with the function number, represent the function number of the message that has caused the

error with the first Bit set to 1 (ex. the function 3 becomes 0x83) The error code could be one of the

followings:

Error Code

NOTE: If you write a parameter's value equal at his actual value this is a valid transaction

and don't cause an error.

CD3200-1PH from 15A to 110A

Function

Name

ILLEGAL FUNCTION

ILLEGAL DATA ADDRESS

ILLEGAL DATA VALUE

Error Code

Function not supported.

Address out of range.

Attempt to write invalid or action not carried out.

User's Manual

CRC 16

Cause
