CMA Dishmachines UC65e M2 Installation/Operation Manual With Service Replacement Parts page 43

Item Part
No. No.
1 02104.17
2 02104.18
3 00968.00
4 00923.50
5 02104.21
6 02104.22
7 02103.28
8 43030.00
9 02104.25
10 02103.25
11 00721.00
12 02104.28
13 00965.00
14 13826.00
15 43019.00
16 02104.32
17 02104.33
18 02104.34
19 02104.35
20 02104.36
21 02104.37
22 02104.38
23 02104.39
24 02104.40
25 02104.41
26 02100.57
27 02104.43
28 02104.53
29 02104.55
30 02104.57
31 02104.59
32 02104.54
33 02104.56
34 02104.90
35 02104.91
36 02104.92
37 03801.60
Description
GASKET, DOOR
HEATER, WASH TANK, 2KW, 240VAC
WASHER, SPLIT LOCK 1/4"
NUT, HEX 1/4-20
O-RING
ADAPTER, THERMOSTAT
BUSHING, THERMOSTAT
THERMOSTAT, WASH TANK
ADAPTER, THERMOMETER
THERMOMETER, 2" DIAL 7' CAPILLARY
NUT, JAMB 1/2" THIN PATTERN
THERMOSTAT, FIXED, SNAP 212°F
NUT, LOCK 6-32 W/NYLON INSERT
SCREW, 4-40 X 5/8" PAN HEAD
SWITCH, DOOR 15 AMP
BRACKET, SWITCH
PLATE, SWITCH NUT
ELBOW, PUMP SUCTION
GASKET, PUMP SUCTION
FLANGE, PUMP SUCTION
HOSE, 1/4" ID X 3/8" OD
ELBOW, 3/8" TUBE X 1/4" NPT
GASKET, 1/4" FIBER
LOCKNUT, 1/4" PLASTIC
FILTER, SUMP
FILTER, O-RING
TUBE, OVERFLOW
TRAP, AIR
GASKET, AIR TRAP
ORING, NUT, AIR TRAP
NUT, AIR TRAP
CLAMP, HOSE AIR
HOSE, AIR
BRACKET
SCREW, 6-18 X 1/4" PAN HEAD. PHIL.
SWITCH, PRESSURE
NUT, LOCK, 10-32 KEPS
Wash Tank Heater and Drain
Qty.
1
1
4
4
2
1
1
1
1
1
2
1
4
2
1
1
1
1
1
1
A/R
1
1
1
1
1
1
1
1
1
1
2
4FT.
1
1
1
1
37
