CMA Dishmachines UC65e M2 Installation/Operation Manual With Service Replacement Parts page 39

Item Part
No. No.
1 00426.00
2 00912.00
3 02103.77
4 02103.78
5 02103.79
6 50109.00
7 02103.81
8* 02103.82
9 02103.83
10 02103.84
11 02103.85
12 02103.86
13 02103.88
14 02103.89
15 02103.90
16 02103.91
17 02103.92
18 02103.93
19 02103.94
20 02103.95
21 02103.96
22 02103.97
23 02103.98
--- 02103.99
* Note:
The bearing assembly, P/N 2103.82 includes 2 bearings, 1 locknut, and 1 wash arm hub.
The bearings, locknut and hub are not available as separate service replacement parts.
Description
WASHER, 5/16" SS WASHER
NUT, 1/40-20 NYLON LOCK NUT
HUB, UPPER WASH ARM
WASHER, PACKING
SCREW, RETAINING
CLAMP, HOSE #28
HOSE, UPPER WASH ARM
BEARING ASSEMBLY
O-RING, 2-1/8" OD X 1-3/4" ID X 3/16"
HUB, LOWER WASH ARM
MANIFOLD, LOWER FWR
WASH ARM ASSEMBLY (Includes Item 8)
WASHER, NYLITE
BOLT, 1/4-20 X 1"
SHAFT, LOWER
O-RING
HUB, RINSE ARM, MOLDED
SCREW, TRUSS HEAD 8-32 X 1/4"
ARM, RIGHT-HAND RINSE (7 JETS)
ARM, LEFT-HAND RINSE (8 JETS)
CAP, RINSE ARM, 5/16-24
SPINDLE, RINSE ARM
SPACER, NUT
RINSE ARM ASSEMBLY (Includes Items 18-23)
Wash and Rinse Spray Arms
Qty.
4
4
1
1
1
2
1
2
2
1
1
2
4
4
1
1
2
4
2
2
4
2
2
2
33
