CMA Dishmachines UC65e M2 Installation/Operation Manual With Service Replacement Parts page 29

Item Part
No. No.
1 02103.12
1 02103.13*
2 02103.14
3 02103.15
4 02103.16
5 40012.10
6 02103.23
7 02103.19
8 02106.01
9 02103.21
10 02103.22
11 02103.24
12 02103.25
13 03232.00
14 00965.00
15 02103.28
* When the 6kW element is used the minimum supply circuit Ampacity and Overcurrent protection
will need to increase to use a 40 Amp Breaker.
Description
HEATER, BOOSTER 4kW, 208V, 40°F RISE
(Does not include gasket)
HEATER, BOOSTER 6kW, 208V, 70°F RISE
(Does not include gasket)
GASKET, BOOSTER HEATER
THERMOSTAT, CONTROL 195°F
BOLT, HEX FLANGE, 1/4-20 X 3/8"
ELBOW, 3/8" NPT X 1/2" HOSE
TEE, RINSE THERMOMETER
THERMOSTAT, HI-LIMIT FIXED SNAP 240°F
TANK, BOOSTER WELDMENT
CLAMP, GEAR-TYPE, 7/16" SST
HOSE, 1/2" ID
FITTING, BOOSTER THERMOMETER
THERMOMETER, 2" DIAL, 7' CAPILLARY
PLUG, 1/8"
NUT, 6-32 W/NYLON INSERT
FITTING, BOOSTER THERMOSTAT
Booster
Qty.
1
1
1
1
1
1
1
1
1
3
A/R
1
1
2
2
1
23
