CMA Dishmachines UC65e M2 Installation/Operation Manual With Service Replacement Parts page 41

Item Part
No. No.
1 02104.00
2 02103.16
3 02103.18
4 03101.47
5 03101.00
6 02104.05
7 02104.06
8 02104.07
9 02104.84
10 02104.09
11 02104.10
12 02104.11
13 50109.00
14 02104.13
15 02103.81
16 03107.50
17* 02103.68
18 02106.19
19 02106.21
20 02106.23
21 02106.25
22 02106.27
23 02106.17
24 02103.21
* NOTE:
ITEM 17 IS STRAPPED TO THE DRAIN HOSE AS A SEPARATE PART FOR THE
PLUMBING INSTALLER TO USE DURING INSTALLATION.
Description
HOSE, FILL 1/2" X 7' C/W 3/4" FNPS
BOLT, HEX FLANGE, 1/4-20 X 3/8"
HOSE, BOOSTER FILL, 1/2" X 1'
CLAMP, HOSE GEAR-TYPE 5/16"
CLAMP, HOSE GEAR-TYPE, 1"
HOSE, DRAIN PUMP SUCTION
BRACKET, DRAIN PUMP
PUMP, DRAIN 115VAC
HOSE, DRAIN
BRACKET, WASH PUMP
CLAMP, HOSE GEAR-TYPE 1-13/16"- 2-3/4" MAX
HOSE, SUCTION WASH PUMP
CLAMP, HOSE #28
HOSE, DISCHARGE WASH PUMP
HOSE, UPPER WASH ARM
HOSE RUBBER, 1/2" ID X .84" OD
COUPLER, 3/4" MPT X 3/4" HOSE BARB
HOSE, DRAIN MOLDED
NUT, ANTI-SIPHON VALVE
O-RING
BALL, 3/8" DIAMETER, STAINLESS STEEL
WASHER, SILICONE
BODY, ANTI-SIPHON
CLAMP, HOSE GEAR-TYPE, STAINLESS STEEL
Drain Pump and Hoses
Qty.
1
4
1
3
3
1
1
1
1
1
2
1
2
1
1
A/R
1
1
1
1
1
1
1
2
35
